PA filter cartridge F3168

NBRsilicone rubber304 stainless steel

Installation
Product can be installed in any position.

Applications
Used where fluid filtration or control of flow direction (or both) is required.

Physical specifications

• Body: PA66 GF30%
• Gaskets: LSR, NBR
• Filter wire: AISI 304
• Spring: AISI 316

Working specifications

• Working pressure: 0,05 ÷ 10 bar
• Room temperature: 0 - 75 °C
• Fluid temperature: 0 - 75 °C
• Flow direction: Unidirectional
• Nominal diameter: DN3 - DN4

Hydraulic connections

• Inlet: Push-Fit (JG) 4 mm, Push-Fit (JG) 6 mm
• Outlet: Push-Fit (JG) 4 mm, Push-Fit (JG) 6 mm

Datasheets
Model | IN-OUT | Orifice | Check Valve | Filter
F3168 | Push-Fit Ø4 mm | 4 mm | yes | yes
F3170 | Push-Fit Ø6 mm | 6 mm | yes | yes

Characteristics / technical specifications

• Body material: PA66 GF30%
• Gaskets: LSR, NBR
• Filter wire material: AISI 304
• Spring material: AISI 316
• Working pressure: 0,05 ÷ 10 bar
• Room temperature range: 0 - 75 °C
• Fluid temperature range: 0 - 75 °C
• Flow direction: Unidirectional
• Nominal diameter: DN3 - DN4
• Hydraulic connections (Inlet/Outlet): Push-Fit (JG) 4 mm, Push-Fit (JG) 6 mm
• Available models: F3168 (Push-Fit Ø4 mm, 4 mm orifice), F3170 (Push-Fit Ø6 mm, 6 mm orifice)
