OP-8500 offers improved thermal performance and conformability. This material conforms to surface irregularities under low application pressures. It is electrically non-conductive and naturally tacky.
Additional adhesive is generally not required.
The proprietary formulation of OP-8500 is RoHS compliant and halogen-free, providing extra reassurance in applications where hazardous substances are forbidden.
Features and Benefits
3.0W/m-K thermal conductivity
Good compressibility
Naturally tacky
Electrically isolating
RoHS compliant
Halogen-free
Color -
Violet
Thickness Range [inch/(mm -
0.01" (0.25)~0.40" (10.1)
Thermal Conductivity [W/mK] -
3
Hardness [Shore 00] -
40
Operation Temperature [°C] -
-40°C~200°C
Halogen-Free [under 700ppm] -
Yes
