Storage
1*SATA 3.0
1*M.2 (Key-M, 2280, PCIe x4 NVMe)
Expansion Interface
1*M.2 (Key-E, 2230, support Wifi+BT)
1*M.2 (Key-B, 2280, support 4G/5G)
BIOS
- AMI UEFI BIOS
System
- Windows 10/11 64-bit, Linux
I/O Interface
Ethernet
- 2*Intel® Gigabit Ethernet Controller (up to 2.5 GbE), RJ45
Serial
- 1*RS232, 1*RS485
USB
3*Type-A, USB 3.2
2*Type-C, USB 3.2 + DP 1.4a
Others
- 1*eSPI, 1*SPI, TPM 2.0, WDT
Display
Display Interface
1*DP 1.4a++, max resolution up to 7680*4320@30Hz
2*DP 1.4a, Type-C, max resolution up to 7680*4320@30Hz
1*HDMI 2.1, Type-A, max resolution up to 7680*4320@30Hz
1*LVDS, max resolution up to 1920*1200@60Hz
1*Micro HDMI IN, HDMI to MIPI CSI
Multiple Display
- Quad
Mechanical & Environment
Dimension
- 146*102mm
Power Input
- DC 12V
Temperature - Operation: 0℃~60℃, Storage: -20℃~75℃
Relative Humidity
- 5%~95% RH (non-condensing)
