Digital input module FDCI221

for monitoring systemDIN rail-mountedIP65

Product description
For the connection of one monitored potential-free make-or-break contact for indication of technical states (e.g. door or ventilation control) or for alarm actuation (e.g. sprinkler alarm). The module provides one potential-free input monitored for open-circuit and short-circuit (termination resistors). The input can be configured via the fire control panel for status or alarm messages. Status indicated by LED. Power supply via FDnet/C-NET. Input module includes 2 resistors and 2 mounting feet for TS35 U-rail.

Identification

• Product No.: FDCI221
• Stock No.: S54312-F1-A1
• GTIN / EAN: 4047625029180

Documents (selection available)

• Datasheet
• Certificates (VdS, LPCB, DNV MED D QS, Certificate of constancy of performance, UKCA)
• Declarations (EC Declaration, Declaration of Performance, RCM Declaration, EC Declaration - MED)
• Environmental Product Declaration
• Installation Instructions

Accessories

• FDCH221: housing for FDCI221 and FDCIO221 (enables IP65)

Technical specifications

• Operating temperature: -25…70 °C
• Storage temperature: -30…+75 °C
• Standard: EN 54-17, EN 54-18
• Protection category: IP30 (IP65 with external housing)
• Relative humidity: ≤95 % rel.
• Operating voltage: DC 12…33 V
• Cable capacity: 0.2...1.5 mm2 (2.5 mm2)
• System compatibility: FDnet -> FS20; C-NET -> FS720
• Communication protocol: FDnet/C-NET
• Quiescent current: Max. 0.3 mA
• Dimensions (W x H x D): 95 x 71 x 23 mm
• Color: Pure white, RAL 9010
