type K thermocouple / type J thermocouple / type T thermocouple / type E thermocouple

{{requestButtons}}

Characteristics

  • Technology:

    type K thermocouple, type J thermocouple, type T thermocouple, type E thermocouple, type S thermocouple

  • Mounting:

    insertion, screw-in, flange, SMD, plug-in

  • Other characteristics:

    stainless steel, mineral-insulated, with handle

  • Applications:

    for surface temperature measurement, for pipes, for liquids, for gas, food, for pipelines

Description

Simplex, duplex or multipoint thermocouples with grounded, ungrounded, exposed hot junction, and multitude of fitting options. Cold junction ended in bare wires, connector, head or with pot seal and extension wire.

Sensors with handle to measurement gases, liquids, surfaces, frozen food, pipes, etc.

Calibration: E, J, K, N, T, B, R, S, W3 and W5. Class 1 and 2.
Sheath diameter: from 0.25 to 12 mm
Sheath material: stainless steel (ANSI 304,310,316,446…), Inconel, Nimonic, molybdenum, titanium, platinum, tantalum and rhenium.
Internal insulation: magnesium, aluminum, beryllium or hafnium oxide powder with high degree of compaction.
