Pneumatic cylinder CC series
double-actingsteelaluminum

pneumatic cylinder
pneumatic cylinder
Add to favorites
Compare this product


Characteristics

Type
pneumatic
Configuration
double-acting
Material
steel, aluminum
Applications
brake
Stroke

1,372 mm, 3,505 mm, 7,163 mm (54.016 in)

Force

86.3 N, 193.5 N, 346.5 N

Description

The Tolomatic double acting pneumatic air cylinder offers the widest variety of sizes and options Double acting pneumatic air cylinders offer a cost savings over rod cylinders when strokes exceed four feet and provide a versatile space-saving design. • Strokes up to 7308 mm (287 in). Using couplers stroke lengths of 18 m (720 in) are possible • 9 different bore sizes from 13 to 127 mm (1/2 to 5 in) • Optional auto tensioners keeps cable rigid and extends cable and gland seal life • 3-ported heads for convenient connection • Aluminum tube standard; steel option available for strength • Caliper disc brake option for additional holding force in vertical applications
