Power transformer ET seriescast resinsingle-phasefloor-standing
Add to favorites
Compare this product
Characteristics
- Type
- power
- Configuration
- cast resin
- Electrical characteristics
- single-phase
- Mounting
- floor-standing
- Other characteristics
- adapter, laminated
- Electric power
Max.: 74.7 kVA
(101.5637 hp)Min.: 0.03 kVA
(0.0408 hp)- Primary voltage
Max.: 1,000 V
Min.: 50 V
- Secondary voltage
Max.: 1,000 V
Min.: 12 V
- Primary current
16 A, 25 A, 63 A, 100 A, 200 A
Description
Single-phase matching transformers
Designed and tested according to
IEC/EN 61558-2-1
VDE 0570-2-1
EN 60076-1
UL 5085-2
CSA 22.2 No. 66
Typical applications
Voltage adjustment
Basic equipment
Separate windings
Insulation class B / F from 6.3 kVA
Ambient temperature –25 bis 40 °C
Connection terminal (<63 A)
Frequency 50/60 Hz
