Windows HD Duplicator/Sanitizer UB9XXS

tabletopwith data eraser

Overview
The Intelligent 9 USB Duplicator and Sanitizer is a standalone USB duplicator that enables fast, PC-free duplication and sanitization of USB flash drives and external USB HDDs. It supports high-speed copying at up to 2 GB/min per port and does not require resetting between copies (plug and go).

Features

• High-speed copy supporting up to 2 GB/min per port
• Ergonomic design for easy operation
• Quick socket swap module
• Advanced multi-core processor
• Complete standalone system (no computer required)
• Compatible with USB 1.1/2.0/3.0/3.1/3.2 devices and external USB HDDs
• Supports all formats, data sizes and memory capacities for bit-for-bit copy
• DoD Erase function compliant with DoD 5220-22 (data sanitization)
• Two professional diagnostic tools for flash modules: Capacity Check and H5 Write/Read Test
• Quick data copy (copies only data-containing areas) with support for FAT16/32, Linux ext2/ext3 and NTFS
• 2-second format option; three models available for selection
• Supports synchronous and asynchronous modes for Copy/Compare/Erase/Format
• Strict bit-by-bit hardware comparison for reliable duplication
• User-friendly interface with real-time information LCD
• Firmware upgrade available

Diagnostic & Quality Tools

• Capacity Check: Verifies initial and final sector of connected flash device within ~2 seconds
• H5 Write/Read Test: Overwrites and verifies machine-generated values across NAND flash sectors, then formats to FAT if passed
• Media Check: Bit-by-bit inspection to detect bad sectors
• Measure Speed: Measures read/write speeds (approx. 10 seconds) to estimate duplication durations

Additional Features (Gold Series models)

• Event-log Reporting: Records detailed logs of duplication tasks (time, function, model, serial number, results)
• Burn-in Test: Set duration and loops (30 minutes to 30 days) to test device durability
• Write Protect: Option to set duplicated USB drives as permanently read-only
• Dual Source Compare Mode (DSCM): Use two sources for redundant comparison to guarantee 100% accuracy

Copy Modes

• Quick Copy Mode: Copies only data areas; supports Windows (FAT16/32/64/NTFS), Linux (ext2/ext3/ext4), Mac (HFS/HFS+/HFSX)
• Whole Media (bit-by-bit) Mode: Copies the entire source from initial sector to end for maximum accuracy

Sanitization Functions
Erase functionality complies with NIST SP 800-88r1 and DoD 5220-M standards. Sanitization modes include Quick Erase, Full Erase and DoD Erase.

Hardware / Usability

• Real-time monitoring via PC through USB link (except specific lower-end models)
• Swappable modular sockets and handscrew faceplates for quick maintenance
• Front-panel LCD with navigation buttons and 4 push-buttons (▲, ▼, OK, ESC)
• 3 LED indicators per port: Yellow (Power), Green (Pass), Red (Fail)

Compliance & Standards

• Meets recognized data security standards and regulations (examples cited: GLBA, PIPEDA)
• Certifications reported: FCC, CE, REACH, MIL-STD-810G
• Compliance references: NIST SP 800-88r1, ISO 27000

General
Model: UB910S, UB920S, UB930S, UB940S, UB960S, UB9120S
Target: 9, 19, 29, 39, 59, 119

Specification (summary)
Maximum Transfer Speed: 2 GB/min (actual dependent on device transfer speeds)
Capacity: Supports the largest device sizes on the market
Operating Type: Stand-alone, FPGA-based operation (non PC-based)
Supported Languages: English, Japanese
LCD Display: Backlit monochrome LCD display
LEDs: 3 LED indicators per port (Yellow Power, Green Pass, Red Fail)
Control Panel: 4 push buttons (▲, ▼, OK, ESC)

Supported Formats, Devices & OS
Compatible Devices: USB1.1/2.0/3.0/3.1/3.2 devices and USB-HDDs
Compatible with eUSB (USB DOM) 2.54mm and 2.00mm (with required adapter)
Supported Formats: Quick Copy supports FAT16/32/64, NTFS, Ext2/Ext3/Ext4, HFS/HFS+/HFSX; Whole Media copies bit-by-bit including proprietary formats; supports GPT and MBR
Supported O/S: Stand-alone operation; works with Windows/Mac/Linux when using PC monitoring tools

Power & Environmental
Power supply: Adapter input 100-240 VAC / 47-63 Hz / 1.6 A Max; typical outputs listed per model families (e.g., 12 VDC / 9 A for smaller units; 12 VDC / 12.5 A for larger UB9XXS models). Each USB 2.0 port supports up to 2 A.
Working Temperature: 5°C ~ 45°C (41°F ~ 113°F)
Storage Temperature: -20°C ~ 85°C (-4°F ~ 185°F)
Working Humidity: 20% ~ 80%
Storage Humidity: 5% ~ 95%

Specifications / Technical Data

• Product series: USB Silver/Gold Series
• Model numbers (examples): UB910S, UB920S, UB930S, UB940S, UB960S, UB9120S
• Targets available: 9 / 19 / 29 / 39 / 59 / 119
• Maximum transfer speed: up to 2 GB/min per port (device-dependent)
• Operation: Stand-alone FPGA-based duplicator (non-PC based)
• Languages supported on-device: English, Japanese
• Display: Backlit monochrome LCD
• Indicators: 3 LEDs per port (Power/Pass/Fail)
• Control: 4 push buttons (▲, ▼, OK, ESC)
• Copy modes: Quick Copy (data-area) and Whole Media (bit-by-bit)
• Compare: Hardware bit-by-bit comparison
• Sanitization modes: Quick Erase, Full Erase, DoD Erase
• Power input: 100-240 VAC; adapter outputs vary by model (12 VDC outputs specified by model)
• Operating temp/humidity: 5°C–45°C / 20%–80%
• Certifications & compliance: FCC, CE, REACH, MIL-STD-810G; references NIST SP 800-88r1, ISO 27000
