Gate valve
with handwheelthreadedstainless steel

gate valve
gate valve
gate valve
Add to favorites
Compare this product


Characteristics

Type
gate
Operation
with handwheel
Body
threaded, stainless steel, cast, carbon steel, forged steel
Applications
industrial
Other characteristics
standard, in-line, pressure seal

Description

Vatac Pressure Seal Power Station Gate valves are intended for high pressure, high temperature applications in all types of fluid except where severe coking is a factor. The design and material selections provide excellent service in steam-generation stations, industrial chemical plants and thermal power plants. Vatac Pressure Sealed Power Station Gate Valves are offered in both Cast and Forged Steel body. These options make the Vatac Pressure Seal Power Station product line an excellent choice for users with various application requirements. Vatac Pressure Seal Power Station Gate Valves provides the most efficient flow passage and sealing features possible, resulting in significant weight savings, easy installation and in-line maintenance. Supplied with standard features as below: » Standards to API 600, API 602, ASME B16.34 or DIN3202 » P.T Ratings to ASME B16.34 » Face to Face dimensions to ASME B16.10 » Flanged Ends to ASME B16.5, ASME B16.47 Series A or B » Butt-weld Ends to ASME B16.25 » Threaded Ends to ASME B1.20.1 » Socket-weld Ends to ASME B16.11 » Valves Marking to MSS SP-25 » Inspect & Tested to API 598 » Size Ranges from 1/2” thru 24” » Pressure Ratings from Class 600 to Class 2500, PN110 to PN420 » Structures in Pressure Sealed Union Cover » Ends Connections in Flange, Threaded, Welded and Goove Ends » Body Materials available in Cast or Forged Carbon Steel, Stainless Steel, Duplex Steel, Special Materials etc. » Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials » Actuations can be equipped with Handwheel, Gear Device, Electric / Pneumatic or Hydraulic Actuators
