Diaphragm valve
with handwheelelectricpneumatic

Diaphragm valve - Vatac Valves (Wenzhou) Corporation - with handwheel / electric / pneumatic
Diaphragm valve - Vatac Valves (Wenzhou) Corporation - with handwheel / electric / pneumatic
Diaphragm valve - Vatac Valves (Wenzhou) Corporation - with handwheel / electric / pneumatic - image - 2
Diaphragm valve - Vatac Valves (Wenzhou) Corporation - with handwheel / electric / pneumatic - image - 3
Add to favorites
Compare this product

Characteristics

Type
diaphragm
Operation
with handwheel, electric, pneumatic
Body
straight, in-line
Other characteristics
ANSI, DIN

Description

The Vatac Unlined Straight Through diaphragm valve provides a reliable and economic olution in a variety of slurry applications. The valve is easily maintained in-line and there are no packing glands to maintain. The diaphragm is able to close over suspended solids. » Size Ranges: 1/2” through 14” » Pressure Ratings: ANSI #125, #150, PN6, PN10, PN16 » Standards compliance: ASME B16.34, DIN 3202, BS 5156, ASME B16.10, MSS SP-71, BS EN558, ASME B16.1 CLASS 125, ASME B16.5 CL150, EN1092, EN12226, ISO 5208, API 598, BS 4504 or equivalents » Materials: Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel, or Other Specials » Ends Connections: Flanged RF or FF » Optional Locking Device » Position indicator » Optional Direct Mounting to ISO 5211 » Regular Bore » Handwheel, Electric or Pneumatic operated
