Inflatable shutter RDK series

for pipesbypass

Overview

Safely seal or divert pipes.
Protect sewage systems and groundwater from serious contamination. Vetter pipe-sealing bags FS allow emergency teams to stop or divert hazardous liquids and gases quickly and controllably using a hose connection. The bags adapt individually to different pipe diameters and offer high resistance to chemicals and heat, making them suitable for fire services and environmental protection operations.

Available configurations

• Bypass Bags FS
• Pipe-Sealing Bag FS

Pipe diameter options

• 7-15 cm / 2.76 - 5.91 in
• 10-20 cm / 3.94 - 7.87 in
• 20-40 cm / 7.87 - 15.75 in
• 20-50 cm / 7.87 - 19.69 in
• 30-60 cm / 11.81 - 23.62 in
• 50-100 cm / 19.69 - 39.37 in
• 50-120 cm / 19.69 - 47.24 in
• 80-140 cm / 31.5 - 55.12 in

Product identifiers
Product number: 1482000900

Technical data
Product number: 1482000900
Weight: 3.5 kg
Air requirement at working pressure [l]: 160
Pipe diameter: 20-40 cm / 7.87 - 15.75 in
Test pressure: 1.95 bar / 28.28 psi
Operating pressure: 1.5 bar / 21.76 psi
Diameter: 19.5 cm / 7.68 in
Cylinder length: 65.5 cm / 25.79 in

Specifications / technical features

• Intended use: safely seal or divert pipes to protect sewage systems and groundwater
• Designed for fire services and emergency response teams
• Adjustable to different line diameters for a secure fit
• Resistant to chemicals and elevated temperatures
• Available as Pipe-Sealing Bag FS and Bypass Bags FS
• Multiple pipe diameter ranges available (see Pipe diameter options)
• Air requirement at working pressure: 160 l
• Test pressure: 1.95 bar (28.28 psi)
• Operating pressure: 1.5 bar (21.76 psi)
• Main dimensions: diameter 19.5 cm (7.68 in), cylinder length 65.5 cm (25.79 in)
• Weight: 3.5 kg
