Electric locomotive ES43ACmi

dieselpassengerfreight

Overview
The Evolution Series ES43ACMI by Wabtec is a diesel-electric, multipurpose double-cab locomotive designed for passenger and freight operations in high-ambient temperature and dusty environments. It combines proven platform experience with fuel-efficient operation, high reliability and a design compatible with U.S. EPA Tier 2 emissions requirements.

Key features

• Two air-conditioned cabs (double-cab)
• Fuel-efficient diesel-electric powerplant
• AC individual-axle traction control (single-axle control)
• Auxiliary Power Unit (APU)
• Advanced cooling system for high ambient temperatures and dusty conditions
• Designed for mixed passenger and freight use
• Global operating experience from the Evolution platform (≈8,000 units)

Specifications

• Number of powered axles: 6
• Maximum weight: 123 tonnes
• Weight per axle: 22 tonnes
• Track gauge: 1676 mm
• Emissions: up to U.S. EPA Tier 2
• Horsepower (Gross): 4,500 HP (3,356 kW)
• Horsepower (Tractive): 4,365 HP (3,255 kW)
• Starting tractive effort: 500 kN
• Continuous tractive effort (CTE): 425 kN
• Total fuel capacity: 6,300 L
• Useable fuel: 6,000 L
• Engine model: GEVO12
• Maximum ambient temperature rating: 40 °C
