Diaphragm pump WL 1040

waterfor chemicalssolenoid-driven

Product Overview
Compact solenoid pumps are small electromagnetic pumps designed for precise, controlled fluid transfer in space-constrained industrial and OEM applications. The WL 1040 uses an electromagnetic coil and plunger mechanism to deliver repeatable dosing and microfluid transfer with configurable pulse or voltage control.

Key Features
Compact solenoid pumps provide rapid electrical response and accurate metering in a simplified mechanical package. The WL 1040 family supports multiple voltage options and offers configurable duty cycles to match application requirements.

Highlights

• Precision dosing and microfluid transfer for space-critical equipment
• Fast response and flow control via pulse frequency or input voltage adjustment
• Low power consumption and simple mechanical integration
• Suitable for OEM devices, medical equipment, laboratory analyzers, beverage machines and microfluid systems

Product Details (table)
Brand: Weilong Technology
Model Number: WL 1040
Rated Voltage (V): DC 12V or 24V (variants also available in 110V/220V AC)
Rated Power (W): 3–5 W (typical; some variants up to 10–24 W)
Work Model: 2-way valve
Flow Rate: typical adjustable 0.5–1.5 L/min (datasheet ranges and table entries vary)
Resistance: 25 Ω
Reset Time: 0.3 s on / 0.3 s off
Service Life: up to 1,000,000 cycles for certain configurations
Certifications: CE, RoHS, ISO9001
Material: carbon steel housing with Teflon plating
Lead Wire Length: 200 mm
Install Style: adjustable screw
Dimension Tolerance: ±0.1 mm
Water-proof: none specified
Insulation Class: F (155 °C)
Hi-Pot Test: AC 600V 50/60Hz 2s
Non-excitation Holding Force: 0
Working Temperature: -10 °C to 100 °C (table); typical fluid-dependent range 0 °C to 60 °C
Duty Cycle: configurable 1–100%
Thread Depth: /
Payment Term: TT or LC at sight
Sample Order: available
Warranty: 1 year
MOQ: 1000 pcs
Supply Ability: 5000 pcs/week
Delivery Time: ~30 days
Port of Loading: Shenzhen

Product Datasheet (typical specifications)

• Voltage variants: 12V DC, 24V DC, 110V AC, 220V AC
• Power consumption: typical 3–5 W (some variants 10–24 W)
• Flow rate: typically 0.5–1.5 L/min (adjustable)
• Max pressure: typically 2–5 bar (20–70 PSI)
• Operating temperature (fluid dependent): 0 °C to 60 °C (typical)
• Duty cycle: continuous or intermittent (model dependent)
• Port size: 6 mm (1/4") or 8 mm (5/16") barbed or threaded
• Wetted materials: diaphragm EPDM or Viton; housing PP/POM; valves stainless steel or ceramic
• Lifespan: commonly 50,000–100,000+ cycles; certain configs up to 1,000,000 cycles

Applications

• Medical equipment: infusion, dosing and diagnostic systems
• Laboratory instruments: reagent dosing and analyzers
• Beverage machines and coffee dispensers
• Water treatment and chemical dosing systems
• Inkjet printing, microfluidics, robotics, smart agriculture, lubrication and cooling systems
• OEM integration for space-constrained automation devices

Advantages & Disadvantages

• Advantages: accurate repeatable dosing, compact footprint for limited-space devices, fast electrical response, simple mechanical design and low nominal power draw
• Disadvantages: pulsating flow due to reciprocating action (may require damping), lower max pressure than some mechanical pumps, sensitivity to particles (requires filtration), reduced performance with high-viscosity fluids, possible overheating if used beyond recommended duty cycle

FAQ (selected)

• Q: Can compact solenoid pumps run continuously? A: Many models are designed for duty-cycle operation; verify the specific model duty recommendations.
• Q: Are they suitable for medical devices? A: Yes, when appropriate wetted materials and certifications are selected.
• Q: How is flow rate controlled? A: By adjusting pulse frequency or input voltage.
• Q: Can they pump corrosive fluids? A: Yes, with compatible materials and seals (e.g., Viton or appropriate wetted-material choices).
• Q: What power supply is required? A: Common variants use DC 12V or 24V; AC options exist for certain models.

Technical specifications

• Brand: Weilong Technology
• Model: WL 1040
• Voltage options: 12V DC, 24V DC, 110V AC, 220V AC
• Rated power: 3–5 W (typical); other variants up to 10–24 W
• Work model: 2-way valve
• Flow rate (typical): 0.5–1.5 L/min (adjustable)
• Max pressure (typical): 2–5 bar
• Resistance: 25 Ω
• Reset time: 0.3 s on / 0.3 s off
• Service life: up to 1,000,000 cycles (model dependent)
• Certifications: CE, RoHS, ISO9001
• Housing material: carbon steel with Teflon plating
• Wetted materials: EPDM/Viton diaphragms; PP/POM housing options; stainless steel or ceramic valves
• Lead wire length: 200 mm
• Installation: adjustable screw
• Dimension tolerance: ±0.1 mm
• Operating temperature: -10 °C to 100 °C (table); typical fluid-dependent 0 °C to 60 °C
• Duty cycle: configurable 1–100%
• Sample order: yes
• Warranty: 1 year
• MOQ: 1000 pcs
• Supply ability: ~5000 pcs/week
