Tube cutting machine CTL-6S
cablebenchtopautomatic

tube cutting machine
tube cutting machine
Add to favorites
Compare this product


Characteristics

Product handled
for tubes, cable
Configuration
benchtop
Other characteristics
automatic, programmable
Tube diameter

6 mm (0 in)

Description

Product Description The CTL-6S is an automatic saw that comes standard with programmable part quantity and programmable cut length (in/mm). 80 psi shop air ensures that the tube is clamped during the cutting process. A material low indicator is used to sense the end of the material and alerts the user to load the next straight length for processing. The software doesn’t miss a beat, keeping track of the number of parts cut as a new straight length is loaded into the machine. Refrigeration lengths of copper and aluminum can be processed with this benchtop system. Thin wall steel, aluminum, brass, and copper tubing can be cut using this technique as well. Shown with optional M6 straightener & payoff for flexible coax cable. Automatic feed & cut...that is what the CTL-6S saw is designed to do. The CTL-6S (shown with optional straightener and payoff) is a benchtop saw cutter that automatically feeds and cuts straight lengths of tubing (<3 mm dia. tubing), semi-rigid coax (<6.35 mm dia. maximum), flexible coax (<6.35 mm dia.) and solid rod (<1.2 mm dia.). Designed for production, the CTL-6S with automatic feed makes use of a carbide saw blade to cut through small diameters. With the material clamped, the programmable cross feed moves the saw blade through the material with 20 programmable feed settings.
