Butterfly valve WT electrically-actuatedcontrolANSI
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- electrically-actuated
- Function
- control
- Other characteristics
- ANSI, bidirectional, quarter-turn
- DN
Max.: 2,800 mm
(110.236 in)Min.: 80 mm
(3.15 in)- Pressure
Max.: 26 bar
(377.1 psi)Min.: 1 bar
(14.5 psi)- Temperature
Max.: 650 °C
(1,202 °F)Min.: -196 °C
(-321 °F)
Description
WT series features "oblique elliptical disc radial dynamic balance seal system", Non-rubbing seating, metal to metal seal.
QRM and QRE series piston type quarter-turn actuator can be used with W9 series valve, and EMR series are electric actuator for these valve.
Elimainating seat-seal friction on unseating cavitation and noise reducers are available to complement the valve under high pressure drop process situation.
120~439040
ANSI Ⅳ, Ⅴ or Ⅵ, bidirectional seal or according to API 598 standard
