ASSEMBLY ROBOTS:
Several models are available for a variety of assembly applications including the unique dual-arm SDA10D robot, the compact HP3 robot and the 7-axis SIA20D robot.
The slim, dual-arm SDA10D robot is strong, quick and agile. It provides human-like flexibility with 15 axes of motion (7 axes per arm, plus a single axis for base rotation). Powerful actuator-based design and best-in-class wrist characteristics make the SDA10D robot ideally suited for a wide variety of assembly, part transfer, machine tending, packaging and other handling tasks that formerly could only be done by people.
The compact, high-speed HP3 robot requires minimal installation space. It offers superior performance in small part applications such as assembly, dispensing, packaging, material handling and machine tending.
The SIA20D (Slim In-line Arm) robot features a revolutionary 7-axis design with best-in-class wrist performance characteristics that enables amazing freedom of movement, coupled with the ability to maneuver in very tight areas. Short axis lengths and extreme motion flexibility allow the slim SIA20D manipulator to be positioned out of the normal working area without limiting the motion range of any axis. The agile, versatile SIA20D opens up a wide range of industrial applications to robots and is ideal for assembly, injection molding, inspection, machine tending and a host of other operations.
|
|
When the heat is on, KUKA robots in the foundry version get the job done without even breaking a sweat. Far from it: for years they have been used successfully in a wide range of foundry, ceramics or glass industry applications, ensuring that tasks are carried out faster and more efficiently.
|
|
A 4-axis, multi-articulated robotic palletizer requiring minimal space to completely automate product loading and unloading. With a 310 lb. (140 kg) lifting capacity, its an ideal tool to relieve the burden from your employees, eliminating repetitive motion and back injuries associated with manual palletizing.
Columbia/Okura robots are easy to operate and backed by 24 hour, U.S.-based parts and service support.
|
|
PRESS TENDING:
Motomans EPH-series Expert Press Handling robots set a new standard for speed with large robots and are specifically designed for the rigors of press tending. EPH-series press tending robots feature payloads from 100-200 kg (220.5-441.0 lbs) and come in floor- and shelf-mounted configurations. Shelf-mounted versions allow improved clearances for ease of die changes. Large work envelopes allow EPH models to be used to tend presses with spacing from 4-7 m (13-22.9 ft).
Compared to general-purpose robots, EPH-series press tending robots feature higher performance drive systems on the S, L and U axes (axes 1, 2, 3) for high duty cycle applications. These robots also feature a high vibration rating of 9.8 m/s2 (1.0G), which is needed for the press room environment. They can also be used anywhere that high-performance handling is required.
|
|
|
A 4-axis, multi-articulated robotic palletizer capable of handling 25 cycles/min.for bags (24 bpm) and 20 cycles/min. for cases (up to 120 cpm). They're easy to operate and designed to fit into tight spaces while maximizing the working envelope. With 150+ U.S. installations, and 24 hour U.S. based parts and service support, Columbia/Okura robots provide the best robotic palletizing solution available.
|
|
|
|
|
|
SPECIMEN PROCESSING AUTOMATION:
Motomans AutoSorter III is a compact, fully integrated pre- and post-analytic specimen processing instrument that is ideal for hospital and medical center laboratory environments. Designed to improve processing accuracy and relieve laboratory staff of repetitive tasks, AutoSorter III provides fast, accurate and reliable specimen sorting, centrifugation and decapping.
AutoSorter III permits use of a wide variety of specimen tube configurations and instrument racks. It may be used as a stand-alone workcell for specimen processing, or may be connected to a track system for direct transfer of specimens to and from diagnostic instruments. It also consolidates post-analytic specimens and creates inventory files for archive consolidation.
Motoman provides automated clinical laboratory specimen processing solutions for sorting; aliquoting; decapping/recapping; thawing/mixing; centrifugation; and archive storage and retrieval -- with a range of standard platforms. AutoSorter solutions can be customized to develop unique work cells to meet each laboratory's unique specimen processing needs.
|
|
FANUC Robotics manufactures reliable and performing industrial robots for a wide range of applications, present in many industries: automotive (OEM and suppliers), metal, food & beverage, machine-tool, chemicals and pharmaceuticals, wood, electronics, paper
The FANUC robot range can answer all industrial needs with more than 50 different models, with a payload form 2 to 700kg and 4 to 6 axes.
All robots run with R-J3iC controller, which uses high-performance hardware and the latest control technology to enhance not only robot basic functions, but also many intelligent functions such as:
Control of up to 40 axes: up to 4 robots can be controlled by a single controller together with 4 additional axes groups
Integrated vision system to speed-up the installation of vision applications
Wide range of fieldbus connections
Easy backup and restore (PCMCIA, USB)
Enhanced security and reliability
Wide choice of software options
|
|
|
|
|
|
|
As a robotics pioneer, the KUKA Robot Group is one of the leading suppliers of industrial robotics. KUKA today offers a uniquely wide range of industrial robots and robot systems, covering all common payload categories and robot types. This means that KUKA always offers you the robot that is exactly customized for your application and industry, for example six-axis robots of all sizes, palletizers, gantry robots, cleanroom robots, robots made of stainless steel, heat-resistant robots, SCARA robots or welding robots. For standard or shelf-mounted robots and heavy-duty versions, mounting is possible on the floor or on the ceiling, making them multifunctional and flexible. The modular structure of KUKA robots means they can quickly and easily be reconfigured for other tasks. All robots operate with a dependable PC-based control platform. This PC-based robot controller (KR C) allows you to use all the advantages of PC technology, such as remote diagnosis, Microsoft Windows interface, field bus, Soft PLC, OPC Server and much more.
|
|
|
|
|
|
FANUC Robotics manufactures reliable and performing industrial robots for assembly applications, present in many industries: automotive (OEM and suppliers), metal, machine-tool, wood, electronics
The FANUC robot range can answer all assembly needs with more than 50 different models, with a payload form 0.5kg to 1350kg and 4 to 6 axes.
All robots run with R-30iA controller, which uses high-performance hardware and the latest control technology to enhance not only robot basic functions, but also many intelligent assembling functions such as:
Control of up to 40 axes: up to 4 robots can be controlled by a single controller together with 4 additional axes groups. 2 or more robots can work together to perform assembling, screwing, glueing operations
Integrated vision system to speed-up the installation of vision applications. This enables easy unmanned operation
Wide range of fieldbus connections to communicate with a complete production line
Easy backup and restore (PCMCIA, USB)
Enhanced security and reliability
Wide choice of software options
|
|
|
As a robotics pioneer, the KUKA Robot Group is one of the leading suppliers of industrial robotics. KUKA today offers a uniquely wide range of industrial robots and robot systems, covering all common payload categories and robot types. This means that KUKA always offers you the robot that is exactly customized for your application and industry, for example six-axis robots of all sizes, palletizers, gantry robots, cleanroom robots, robots made of stainless steel, heat-resistant robots, SCARA robots or welding robots
|
|
|
|
|
|
Assembly operations with robots can make the process faster, more efficient and more accurate.
Robots, many of them equipped with vision technology to aid in handling, have saved workers from tedious and dull assembly jobs, while increasing production and quality.
With robots, your assembly operations can produce consistent high quality output, 24 hours a day, all year round. They will eliminate downtime, reduce labor costs and provide a high return on your investment.
Challenge, for example, the 15-axis dual-arm MOTOMAN-SDA10 robot with your assembly tasks.
MOTOMAN, the robotic division of Yaskawa Electric Corporation, is one of the world's leading robot manufacturers with more than 200,000 robots installed world-wide.
We provide the widest range of robots, including application dedicated robots for welding, palletising, handling, painting and clean-room applications, as well as turnkey welding systems with the highest possible quality of operations.
Interested in knowing more? Please contact us!
|
|
The World's Largest
Electric Articulated-Arm Robot
3,675 lb. (1670 kg.) Maximum Capacity at Extended Reach
Features
-Large "height=width" work envelope
- 360 Spin Axis Rotator
-Pitch Torque up to 108,000in.lbs. (12,200Nm)
-Grip force up to 9,700 lbs. (4,400 kg.)
|
|
Material handling typically requires fast top speed for covering a large area quickly, as well as a large and efficient work envelope. The Nachi SC Series robot has this combination of high top speed, fast acceleration, and high accuracy to move efficiently. Nachi's conveyor synchonization option provides the ability to track along a moving conveyor or table.
Nachi robotic series applicable to material handling:
SH Series
SC Series
SG Series
VS05 Series
|
|
System: Workpiece loader for weights up to 250 Kg (560 lbs)
Application: Milling, drilling, grinding, wire -EDM and other technologies
Connection to CNC: Serial; M-Function; Parallel I/O Bit
Workpiece Identification: EWIS (TM) Rapid
Technical Data
Max. transferweight: 250 Kg
Axis travel in X: 1600 mm
Voltage: 3x400 V+PE
Pneumatic consumption: 200 l/min at 5 bar (73.5 psi)
|
|
FANUC Robotics manufactures reliable and performing industrial robots for a wide range of applications, present in many industries: automotive (OEM and suppliers), metal, food & beverage, machine-tool, chemicals and pharmaceuticals, wood, electronics, paper
The FANUC robot range can answer all industrial needs with more than 50 different models, with a payload form 0.5kg to 1200kg and 4 to 6 axes.
All robots run with R-J3iC controller, which uses high-performance hardware and the latest control technology to enhance not only robot basic functions, but also many intelligent functions such as:
Control of up to 40 axes: up to 4 robots can be controlled by a single controller together with 4 additional axes groups
Integrated vision system to speed-up the installation of vision applications
Wide range of fieldbus connections
Easy backup and restore (PCMCIA, USB)
Enhanced security and reliability
Wide choice of software options
|
|
|
As a robotics pioneer, the KUKA Robot Group is one of the leading suppliers of industrial robotics. KUKA today offers a uniquely wide range of industrial robots and robot systems, covering all common payload categories and robot types. This means that KUKA always offers you the robot that is exactly customized for your application and industry, for example six-axis robots of all sizes, palletizers, gantry robots, cleanroom robots, robots made of stainless steel, heat-resistant robots, SCARA robots or welding robots.
|
|
A firm grip on continuously outstanding quality
Mitsubishi Electric offers a full range of articulated-arm robots with 5 and 6 degrees of freedom for all kinds of handling tasks with payloads from 1 to 12kg.
RV-2AJ und RV-1A
High performance in the compact class
RV-3SDB und RV-3SDJB
Mid-range reliability
RV-6SD, RV-6SDL und RV-12SDL
Maximum power and reach
|
|
|
|
|
|
Giving your company a long-term competitive advantage is what drives us. It is our dedication to each customer's success, in combination with innovative, easy-to-use, and high quality solutions that have made us the European supplier and global player that we are today.
MOTOMAN, the robotic division of Yaskawa Electric Corporation, is one of the world's leading robot manufacturers with more than 200,000 robots installed world-wide.
We provide the widest range of robots, including application dedicated robots for welding, palletising, handling, painting and clean-room applications, as well as turnkey welding systems with the highest possible quality of operations.
Experience from more than half a century of innovation and development is the foundation for our world leading position in the business segment of arc welding, multi-robot technology as well as in servo technology.
With excellent reliable products and solutions MOTOMAN is dedicated to continuously improve productivity and output quality in various industries all over the world.
MOTOMAN delivers robotic solutions for virtually every industry and application, including arc welding, assembly, coating, dispensing, cutting, material handling, packaging, palletizing, deburring, polishing and spot welding.
With each product you will benefit from our long industry experience and know-how. You can count on us to always deliver the best solutions for your most challenging needs
Interested in knowing more? Please contact us!
|
|
The Nachi product line has been designed with customer needs in mind to optimize robot speed, work envelope, payload capability, accuracy, size, weight and reliability. The capacity range is comprehensive, with common load capacities from 5kg to 700kg. Work envelopes are typically 30% larger than competitive models.
Lightweight designs for quick acceleration also allow for easy robot movement and mounting. And, by packing more capabilities into a highly compact unit, Nachi robots effectively shorten the installation space requirements more robots can operate in a given area.
|
|
|
Many tasks which previously were the sole preserve of linear feed systems can now also be carried out by flexible KUKA shelf-mounted robots. For example, the robot can be integrated into an injection-molding machine, a die-casting machine or a machine tool.
|
|
|
|
|
|
FANUC Robotics is very successful in providing solutions for heavy duty applications. With payload capacity up to 1350kg, the FANUC robots can answer the most complex demands in
Heavy duty spot welding
Handling of heavy work pieces
Palletizing of complete layers
Following models can lift more than 200kg:
The R-2000iB/210F and /250F with 210kg and 250kg payload are the strongest within the worldwide most successful robot series R-2000iB. This 6-axes robot has a wide work envelope thanks to its flip over capacity and is ideal for spot welding, machine tool loading in narrow spaces or material handling.
The M-410iB/300, /450 and M-410iB/700 (300, 450kg and 700kg payload) are part of Europes most sold palletizing robot series M-410. Those 4-axes units are especially designed for palletizing operations with true 100% duty cycle
The impressive M-900iA robots (260, 350, 400 and 600 up to 700kg payload) are the heavy weight units for applications where strength and high inertia are demanded. Their wide reach and very high payload capacity make them ideal for handling, palletizing or heavy duty welding.
The worlds strongest robot M-2000iA/1200 can handle up to 1350kg (with SW option) and M-2000iA/900L robots can lift 900kg of payload with a reach up to 4.68 m.
|
|
|
With payloads of up to 1000 kg, these robots can e.g. handle side panels in automotive body-in-white construction or, in the palletizing variant, carry out tasks in the beverage or building materials industries.
|
|
ST Series
The ST Series was developed in response to customer requests for better performance, greater accountability, heavier payload capacity, improved application cable life, and ease of maintenance in a spot welding robot.
Benefits & Features:
Internal Cable Routing Arm
- Eliminates cable problems
- Improved cycle time
- Internal cable routing arm provides quick recovery from damage to cables, air, and water lines
Easy Maintenance
- Grease application points reduced from 27 points and 27 minutes per robot to 4 points and 4 minutes per robot by utilizing a grease bath design
- Battery replacement cycle is three times longer than previous and features original position reset from the teach pendant
- Available in Floor-Mount and Shelf-Mount
- Five Available Models Capable of Handling Payloads of 70kg, 100 kg, 166kg, and 200kg.
|
|
|
|
|
|
Together with integration partners, FANUC Robotics offers a range of advanced solutions to speed up end of line operations.
With a payload range from 2 to 1200kg, you are sure to find the robot model that best suits your needs:
very high speed M-430iA/2F dedicated to food industry (food grease, up to 120 picks per minute, washable)
High speed M-6iB series (2-10kg payload) for very fast pick&place applications. Higher payloads are managed at high speed with M-420iA-M-421iA robots (40-50kg)
M-410iB series (160-450kg): the most successful palletizing robots in Europe!
M-900iA series (260-700kg) for very heavy payload with highest wrist inertia. Smaller payload can be handled with the top selling M-710iC (20-70kg) or R-2000iB series (100-250kg)
M-2000iA series (900kg - 1200kg) for ultra heavy payloads
Our intelligent software and systems ensure reliable and safe handling operations:
Integrated vision: our latest R-30iA controller comes as standard with all the necessary hardware for 2D vision: just plug a camera and a cable! This is most cost-effective solution on the market!
Line tracking software
Collision Guard to protect robot, tooling and products
Advanced vision for 2D visual line tracking or 3D bin picking
Multi robot control for increased cycle time
|
|
|
|
|
|
Together with integration partners, FANUC Robotics offers a range of advanced solutions to speed up end of line operations.
With a payload range from 2 to 1200kg, you are sure to find the robot model that best suits your needs:
very high speed M-430iA/2F dedicated to food industry (food grease, up to 120 picks per minute, washable)
High speed M-6iB series (2-10kg payload) for very fast pick&place applications. Higher payloads are managed at high speed with M-420iA-M-421iA robots (40-50kg)
M-410iB series (160-450kg): the most successful palletizing robots in Europe!
M-900iA series (260-700kg) for very heavy payload with highest wrist inertia. Smaller payload can be handled with the top selling M-710iC (20-70kg) or R-2000iB series (100-210kg)
Our intelligent software and systems ensure reliable and safe handling operations:
Integrated vision: our latest R-J30iA controller comes as standard with all the necessary hardware for 2D vision: just plug a camera and a cable! This is most cost-effective solution on the market!
Line tracking software
Collision Guard to protect robot, tooling and products
Advanced vision for 2D visual line tracking or 3D bin picking
Multi robot control for increased cycle time
|
|
|
|
|
|
Suitable for picking of primary and secondary foods, the M-430iA/2F and M-430iA/4FH can handle payload of 2kg respectively 4kg and have a long reach of 900mm. Their five axes lend them flexibility to accommodate horizontal or vertical product placement positions.
M-430iA/2P and M-430iA/2PH are 6-axes robots especially designed for pharmaceutical applications with 2kg payload and 700mm respectively 900mm reach.
The anthropomorphic arm design produces a large work envelope that allows the M-430iA/2F to quickly rotate or flip back on itself. The arm can be ceiling or floor mounted. With its high speed axes M-430iA can achieve up to 120 cycles per minute at 1kg payload.
The M-430iA has been designed to meet stringent cleanliness requirements and has a smooth exterior surface with no contaminant trap areas the paint has a high gloss finish and is resistant to acids and alkaline materials.
For regular wash down the robot is sealed to meet IP 67 standards and is equippped with food grade grease.
The M-430iA robots are controlled by the new intelligent R-30iA series controller with fully integrated vision control system iRVision.
|
|
|
Nachi's newest handling robot has a 22kg maximum payload capacity with ample wrist torque and a large working envelope with a maximum reach of 1,722mm. The MC maintains superior performance with high-speed motion and high-positioning accuracy. Its compact arm reduces interference with equipment and is also IP65 compliant. Internal air supply lines and cabling supports numerous applications, while the optional internal pneumaatic valves remove shoulder-mounted valve packages.
|
|
Adept six-axis robots continue Adept's tradition of proven performance and precision. The Adept Viper series of articulated robots is Adept's latest offering in a six-axis configuration. The Adept Viper six-axis robot family is a high-performance line of articulated robots designed specifically for assembly applications.
The Adept Viper six-axis robots are available in two models: the Adept Viper s650 and the Adept Viper s850. The Adept Viper s650 six-axis robot offers a 650 mm reach, while the Adept Viper s850 six-axis robot offers an 850 mm reach. The speed and precision of the Adept Viper line of six-axis robots make them ideal for a wide variety of articulated robotic applications requiring fast and precise automation.
|
|
SMART NJ 130 and SMART NJ 110
The 2 smallest models of the new Smart NJ family are dedicated to medium up to high payload applications, thus maintaining unchanged the characteristics of the NJ family (the parallelogram structure, much more thinner than the NH family one).
These models are suitable for a wide range of applications: spot welding, handling, sealing, machining, foundry and harsh environment applications, press and many others.
Technical Features:
- 110 kg payload at 2.6 meters reach
- 130 kg payload at 3.0 meters reach
- Reduced overall dimensions and wide working volume
- Rapidity and flexibility to optimize the cycle time
- High stiffness
- Space saving design
- Flexibility in terms of configuration of the cell: installation position Floor / Ceiling
|
|
The 6 axis series robots feature an articulated arm with 6 degrees of freedom for high flexibility. The spherical work envelope allows maximum utilization of cell workspace. Additional benefits are the floor, wall and ceiling mount options.
The fully enclosed structure of the robot arm (IP65) is ideal for applications in harsh environments.
|
|
|
|
