The FARO Laser ScanArm® offers numerous new and improved features and several advantages in conjunction with the new FaroArm® Quantum - making it unique on the market for measuring machines.
The FARO Laser ScanArm enables users to inspect parts in detail by capturing huge point-cloud data. Its open architecture enables the user to employ Geomagic, Polyworks, RapidForm and many other third-party software programs.
In conjunction with the right software, the FARO Laser ScanArm tackles all measurement tasks such as inspection, point cloud-to-CAD comparison, rapid prototyping, reverse engineering, and 3D modeling. Its main benefits are the exact scanning of reflective and dark objects - the biggest challenge for all scanning systems.
The FARO Laser ScanArm is compatible with the FaroArm Quantum, Platinum, and Fusion.
Advantages of the FARO Laser ScanArm:
» Up to 30% more accurate: Laser Line Probe up to 30% more accurate than previous model
» Improved surface scanning: Higher performance when scanning dark or reflecting surfaces
» Smaller & lighter: Improved ergonomics through 30% weight reduction compared to previous model
» Faster warm-up: 50% faster warm-up time compared to previous models
» Integrated 7th axis - Higher flexibility: No external electronics and fixtures
» Ergonomic handle: Easy to handle
» Cable-free scanning: The Laser Line Probe is compatible with FaroArm's Quantum Bluetooth® technology
For more information visit: www.laserscanarm.faro.com
|
|
|
|
|
|
FARO Gage: The "All-in-One" Machine Shop Solution
The FARO Gage and Gage-PLUS are the industry's first line of personal Coordinate Measuring Machines (CMMs). With their 1.2m (48") working volume, they are the "mount-it-to-where-you-make-it", truly portable, cost-effective, 3-Dimensional, minimal-training gages for machinists. The FARO Gage line replaces all conventional measuring devices. Save time and money by replacing your cluttered inspection area with the one tool that can do it all.
Bringing new power to in-process inspection and CAD-to-part verification, the PowerGAGE includes a high-powered, easy-to-use programmer module, no-train "player" module, and extremely accurate 4-foot measurement arm. Program it once and you're done, even directly use CAD data for nominal. It was designed by and for machinists to speed through measurement challenges and produce the most accurate results available. Shop-hardened and temperature-compensated, it allows anyone, anywhere to measure in 3-D with previously unheard of precision.
For more information visit: www.gage.faro.com
|
|
|
|
|
|
Coordinate Measuring System can measure all basic geometrical elements such as point, line, plane, circle, arc, ellipse, cylinder, cone and sphere, easily measure 3D size, shape and position error of all components and can complete measuring of the majority work pieces of a modern manufacturer. It is mainly used in the machinery, electronics, moulds, automobiles, space and aviation industry. it has the below speciality,
1. Integrated granite working table and sliding bridge structure improve the movement performance and ensure precision and stability of the whole mechanical system.
2. High precision air bearings with pre-pressing design and free fray are adopted for all guide rails to provide more stable operation and ensure excellent dynamic performance of the machine.
3. High precision natural granite is adopted for three axis guide rails, so that the three axes have the same temperature characteristics, good rigidity and will not deform with the time going on.
4. RENISHAW self-adhesive strap metal reflection grating ruler is with high precision, good stability and convenient debugging.
5. Coordinate Measuring software Rational Dmis with powerful functions provides you with most perfect measuring solutions, simple and friendly measuring interface, which is easy to learn and use.The device is also equipped with a highly effective air processing system to ensure excellent quality of compressed air.
|
|
|
|
|
|
The HandyPROBE™ arm-free probing system, powered by the C-Track™ dual-camera sensor, relies on a combination of advanced photogrammetry and powerful digital image processing. This unique duo generates high accuracy data, and increases the reliability and speed of the measurement process, whether on or off the production line.
The HandyPROBE is a 100% portable CMM that gives you total freedom of movement, and allows you to increase your productivity and quality significantly!
Applications
Inspection
- Part-to-CAD analysis
- First article inspection
- Supplier quality inspection
- Conformity assessment of 3D models against the original
parts/production tooling
- Conformity assessment of manufactured parts against the originals
- Manual and automated statistical analysis
- Multi-shot measurement (up to 30 points/sec.)
Benefits
Handheld, portable device
Total freedom of movement
Automatic alignment setup
Measurement Range Volume Extension
User friendly
Continuous calibration monitoring
Excellent ROI
Automatic data collection & report generation
Technical Specifications
Weight (HandyPROBE): 450 g (1 lb)
Dimensions (HandyPROBE): 204 x 159 x 97 mm
Weight (C-Track): 5.5 kg (12 lbs)
Dimensions (C-Track): 1089 x 174 x 119 mm
Measurement speed: 30 points/s
Single point accuracy: 25 μm
Volumetric performance*: 85 μm
Operating volume: 7.8 m3 (273 ft3)
Operating temperature range: 15-40 °C (59-104 °F)
Operating humidity range (non-condensing): 10-90%
Universal power supply: 100-240 VAC/50-60Hz
Certifications: EN 301 489-1, EN 301 489-3, EN 300 220-1
*Test methods in compliance with the ASME B89.4.22 standard
|
|
|
Continuous development has made scanning technology an indispensable technical production factor. Bridge-type measuring machines from Carl Zeiss, with VAST® and Navigator® technology for example, not only ensure a high level of process stability, they also fit seamlessly into the rough production environment as a result of their sturdiness and compactness. You can read more about the classic PRISMO®, as well as smaller measuring machines such as ACCURA® and CONTURA® G2 here.
|
|
|
The range of particularly wide machines TOTAL STATUS offers more than 60 models different in term from size (500 to 2000 mm), from equipment and environmental conditions. Certain models require a air-conditioned environment, others can evolve/move in a medium of workshop having variations in temperature of 15° and more. Capable of point-to-point measurements, with continuous scanning by contact or optics, machines TOTAL STATUS are equipped with powerful software PCMDIS common to all the range of the machines Hexagon Metrology.
|
|
|
|
|
|
Our proven SOLO solution has been expanded by new software and calibration techniques. By adding an extra camera the total field of view has doubled to 70x320, opening up for a variety of new applications.
Short object-to-camera distances allow for easy setup in crowded environments and with excellent accuracy. Just point the cameras in the direction of the object to be measured and immediately capture 3D coordinates of the probe touch point.
New technology has allowed us to bring the price down to make it the most cost-effective portable CMM available in the market today.
Metronor has delivered portable CMM systems to the most demanding industries for well over a decade and proven that our systems will deliver superior accuracy where and when required.
- High accuracy on large objects
- No setup - just measure
- Handheld Wireless / armless / beaml
- Flexible and versatile
- Affordable capability
- Exceptional 700 field of view
- Unique solution for shaft alignment
- Ideal for narrow and crowded environments
- ess probing
- Tool certification within minutes
- Facilitating 100% assembly line up-time
|
|
|
Metrotomography allows you to measure the interior of a workpiece: all recorded data can be applied to all areas of quality assurance and be evaluated. Non-destructive testing technology, such as assembly inspection, damage and porosity analysis, material inspection and defect checks, is possible as well as traditional evaluation, reverse engineering applications or a comparison of geometries. More on Metrotomography®, the fusion of metrology and tomography, can be found here.
|
|
|
|
|
|
Description
The Dr. Heinrich Schneider Messtechnik coordinate measuring systems meet all of the requirements placed on high measuring accuracy, precise movement, easy operation and flexible use.
Their efficiency is due to a variety of factors: a stable basic unit, excellent optics, various probe and laser systems, flexibly usable sensors and a fast, universal control system. The sturdy granite construction guarantees a rigidity, and thus ensures the system's insensitivity towards mechanical and thermal influences. Contactless measuring scales guarantee backlash-free operation and high measuring accuracy.
The measuring stages are motordriven, the speed of the CNC control can be adapted to the respective function. Moreover, the measuring stage is electronically corrected in all axes; this calibration can be checked at any time and corrected if necessary. The telecentric optics and diode light - with programmable intensity and adapted angle of incidence - are specially coordinated to each other. This eases the measuring of complicated workpieces and even of pieces with low contrast - also in incident light.
|
|
They are basically built for measuring rotation-symmetrical parts such as crankshafts, camshafts, gear shafts, drive and steering shafts.
Especially for the crankshafts and camshafts, all kinds of geometric elements can be measured: diameter, length, radius, oil bore holes, flange bores (lateral image), stroke length, stroke offset, stroke angle, symmetry, radial run-out, axial run-out, roundness, grooves, groove width, groove symmetry, and many more.
|
|
|
Machines of measurement from which guidance is protected. this technology makes it possible to work in aggressive mediums of workshop, there or a machine of traditional gantry measurement quickly becomes inoperative
|
|
|
With PRO® and PRO® T, Carl Zeiss offers the universal measuring machines for the automotive and supplier industries. They are ideal for the initial batch of parts up to analysis – from the first sheet to the first tool, from the cubing model to a complete car body. The most important features: the very high speeds without a loss of measuring accuracy – due in no small part to the RDS CAA sensor carrier – as well as problem-free adjustment to changed production requirements. Read more here.
|
|
|
Machines PRIMA Bi pin are currently the variation of MONOPIN Range PRIMA spearhead of the range of machine with horizontal arm HEXAGON-METROLOGY and are able to cover a great number of applications in Métrologie medium or Workshop. Of an extremely robust design around a structure out of cast iron and steel having received a specific surface treatment chrome hard, range PRIMA offers a robustness and an unequalled longevity.
|
|
G-SCAN RX 2 is a 3D scanning probe for reverse engineering and inspection of complex forms. G-Scan RX 2 gives you minimum engineering downtime compared to all other traditional contact measuring tools.
G-Scan RX 2 is compatible with all Ethernet generation ROMER measuring arms.
G-Scan RX 2 is running with a standard 6 axis arm thanks to an integrating rotating axis inside the camera. Compatible with all existing reverse engineering and surface inspection software
|
|
|
|
|
|
DUO System
A complete and truly portable measurement system consisting of a dual sensor, a probing and a computer system.
Our industry-proven solution has been fused with new technology and design to produce the 3rd generation Metronor portable CMM system. More accurate, more portable and even easier and faster to use than ever. New technology and innovations has allowed us to bring the price down to make it the most cost-effective portable CMM available in the market today.
Whether you are building the best possible aircraft, the highest quality car bodies or a new turbine blade you need exact measurements. Metronor has delivered portable CMM systems to the most demanding industries for well over a decade and proven that our systems will deliver excellent accuracy and functionality.
• Complete and truly portable: One box, 30kg, for complete system including computer and tripods
• Extended probing capabilities including hidden features (450mm with optional Light pen).
• Operator friendly: Probing without beams, wires or arms
• Fast and easy set-up and use.
• No warm-up or leap-frogging required
• No moving parts eliminate re-calibration
• Can be upgraded DUET system
• High-accuracy and flexibility
|
|
Features:
- Portable CMM measures at any location
- Instant tracking technology
- Large measurement volume
- Solid state operation with no moving parts
- Dynamic Referencing
Key Benefits:
Take control to reduce production stops, rework, and scrap
- Measure large objects at any location with a precision system that sets up in minutes
- Perform walkabout measurement without cables, linkages, or beam breaks using lightweight, operator-friendly touch probes
- Reduce multiple setups with the system's large measurement volume
- Measure in confined spaces with the system's small, adjustable footprint
- Measure accurately in unstable environments with Dynamic Referencing (near stamping presses, forklifts, vibrating machinery, etc)
|
|
• High-accuracy natural stone guides permanently ensure excellent measuring accuracy,
• Precision air-cushion bearings,tried and proven thousands of times, assure high measuring accuracy, reduce energy input, and guarantee smooth, low-vibration movement,
• Non-contact scale rules ensure low-wear, high-precision data acquisition on all axes,Resolution: 0,15 µm
• Can be equipped with active vibration damping systems,
• Pneumatic counterweight for Z axis,
• Digital motors.
|
|
The SmartScope® Flash™ 500 offers all the great Flash features and performance in a large travel bridge-design system. Parts move on a precision DC motor-driven Y-axis stage while the optics assembly travels in the X-axis across a stable bridge cross member. This design assures rapid, smooth part translation and robust measurement performance.
An extended Y-axis travel of 600 mm is optional, and 300 mm Z travel is optional.
Every SmartScope Flash 500 is multisensor capable.
Whether your needs call for multisensor now or in the future, your SmartScope Flash is up to the task. Its advanced design allows the additional precision of multiple sensors, including touch trigger probes, micro-probes, and laser scanners. Field retrofits are easily accomplished.
|
|
SmartScope® Quest™ 250 is a full-featured coordinate measurement system that is designed to incorporate optical, touch probe, micro-probes, and laser sensors into a compact, benchtop platform.
It is specifically designed to measure smaller parts, or for situations where space is at a premium. Its rigid structural design provides full access to the measurement volume for fixturing flexibility.
|
|
Flexible Gauge Used at the Shop Floor QM-Measrue:
- Has achieved simple measurement of complicated forms at worksite.
- Allows 3-D measurement in much the same way a gage is used.
- For detailed information, leaflet is available on request.
Manual CMM Crysta-Plus M776/7106:
- Ultimate manual CMM for maximum ease of use
- Allows retrofit to CNC in future.
- For detailed information, leaflet is available on request.
Multiarticular Portable CMM Measuring System SA2-50-18 SpinArm II:
- CMM that has a large measuring space with a 6-axis multiarticular structure
- Excellent in portability and can be carried up to the workpiece position.
|
|
|
|
|
|
subra – Stable, compact and affordable
With the three coordinate measuring machines from Kelch & Links complex workpieces can be inspected flexibly in the manufacturing area. The machines can be used in the measuring room as well as in the workshop. The main structure of the machine is manufactured from granite with large guiding cross slides making a stable basis of the machine, essential for the production environment. Precision air bearings in all axes absorb vibration influences and ensure the necessary accuracy and reliability of the measurement.
The machines are available as manual or CNC execution.
The manual entry-level model is especially economical and easy to handle. During critical triggering situations the manual measurement is supported by a very precise fine adjustment via handwheels.
With Renishaw probes flexible and reliable positioning is possible.
The modern standard software with graphical surface is easy to operate and is equipped with all popular measuring functions. Geometry elements as well as form and position tolerances are also included as well as forms, measuring against CAD data and data import and export. The grahpical measuring simulation on the monitor rounds the quick and comfortable CNC programming off.
|
|
Manual CMM SMART
Measuring area from 500/400/300 up to 800/400/300
SMART but Clever, Coordinate Measuring Machine for easy operation
The manual Coordinate Measuring Machine SMART from THOME Präzision Germany, is very easy to operate.
This manual CMM convinces through a simple service, high precision and robustness
Two handwheels in each axis, permit a fine positioning in all three axis. The big wheel allows the operator a fast positioning of the CMM. With the small wheel the operator is able to make a very precise positioning and a low speed.
Each axis can be single locked by clearly structured switches.
The guides are made of high precision granite in combination with precision air bearings.
The base frame (always included in the delivery) has a double passive vibration damping system.
|
|
|
|
|
|
Werth TomoScope
- World First : Computer Tomography integrated in multisensor coordinate measuring machines (patent pending)
Max. part dimensions:
Ø =90mm; L=200mm
Applications:
Measurement and digitizing of plastic, light metal and graphite parts with Computer Tomography and Werth Multisensor system
- Multisensor Coordinate Measuring Machine for 3D measurements using
the principle of Computer Tomography, in combination with additional
sensors (tactile sensor systems, optical sensors)
- Robust granite base with integrated rotary axis
- Optional second Z-axis for collisionfree operation in multisensor mode
- Mechanically supported motorized precision linear guides on all axes
- In both, design and construction, the measuring machine meets the legal
requirements for a fully protective device accord-ing to x-ray device regulations. Additional safety features have been included over and above
the legal requirements.
-Sensor head with compact x-ray sensor with a resolution of 1024 x1024
pixels
- Image processing system for generating and processing x-ray images
|
|
Werth Benchtop EasyScope CNC
- The gateway multisensor coordinate measuring system with automatic image analysis and CNC positioning.
-·Design: compact and benchtop sized multisensor CMM; L-shaped/cantilever configuration with rigid steel weldment construction and ball bearing guideways; stacked, motorized X-Y stages and steel Z axis ram assembly
-·Measuring Range: X=200 mm; Y=150 mm; Z=200 mm
-·Available Measuring Sensors: Noncontact - Werth image processing (IP) video sensor with fixed telecentric objective; Werth Zoom sensor (patented); Werth 3D-Patch (patent pending); Werth Laser sensor, Contact - Renishaw point to point touch trigger sensor; Werth Fiber (micro) sensor (patented); Werth Contour sensor
-·Applications: plastic connectors and housings; stamped/formed parts; medical industry tools and fixtures; printed circuit boards (PCBs); watch plates; gears; plastic injection molding components
|
|
Mµ-Tos
These machines have the following features, in addition to the customary MORA quality elements:
» The machines are completely enclosed including the x-axis guidance system if required
» All machines operate in continuous, 5-axis mode, with the result, for example, that a total of fifteen axes are active for measurements in a coordinate system in the case of an underfloor system
» Travel speeds up to 850 mm/sec
» Guide rails fully hardened and chromium-
plated safety from rust, excellers mounted in special hardened bushes (bearings); smooth and safe running
» Electronic path encoding system (optical or – in case of coarse dust, etc., magnetic)
» Patented cable-breakage safety system
» High-dynamics drive systems with speeds up to 800 mm/sec.
|
|
These machines have the following features, in addition to the customary MORA quality elements:
» The machines are completely enclosed including the x-axis guidance system if required
» All machines operate in continuous, 5-axis mode, with the result, for example, that a total of fifteen axes are active for measurements in a coordinate system in the case of an underfloor system
» Travel speeds up to 850 mm/sec
» Guide rails fully hardened and chromium-
plated safety from rust, excellers mounted in special hardened bushes (bearings); smooth and safe running
» Electronic path encoding system (optical or - in case of coarse dust, etc., magnetic)
» Patented cable-breakage safety system
» High-dynamics drive systems with speeds up to 800 mm/sec.
|
|
The Coordiante measuring machines DIMENSION and DIMENSION-TWIN were especially designed and constructed for use in harsh conditions where fast and percise measuring is paramount. Here only low-friction percision linear guides of the highest quality are used. Air bearings in combination with granit guides can be used when higher accuracy is required. As with all our CMM machines, the motors and guides are sealed. This helps assure protection from dirt, damage, and thermal influences. Highly dynamic, high quality servo-motors provide an exact and vibration-free positioning.
Our manually controlled machines have integrated handwheels, as well as easy to use fixation controls for all axis.
|
|
Werth FlatScope FQ
- the new generation of high speed scanning :
- Design: High-grade matrix scanner with telecentric imaging optics.
- Measuring range: X=400 mm; Y=200mm
- Available Measuring Sensors: Noncontact - Werth image processing (IP) video sensor
- with fixed telecentric objective and
- high-resoluting CCD camera
- Applications: Time critical applications in shopfloor environment.Very suitable for production-integrated quality assurance of profile sections and stamped parts . Measurement of thin foils, printed circuit boards (PCBs), laser-cut and fine stamped parts.
|
|
Singleturn - Vert-X 13E
High protection class IP69
Very compact dimensions
Non-contacting measuring method
Very long life
High accuracy of measurement
Use in cramped installation conditions
|
|
|
The LAMBDA carries out the quadrature of the circle which consists in associating great capacities of measurement, a high rate of travel and an excellent measuring accuracy. One or more gantries ensure measurements on sizes of machine being able to reach more than 20 meters.
|
|
|
|
