HIGH-TECH replacement for VA METERS
The MASS-VIEW® flow meter series are a digital alternative to the conventional variable area meters. The MASS-VIEW® flow meter series incorporates a digital bar graph of actual gas flow as well as indicating flow units, gas type and totalised figures.
The MASS-VIEW® series operates on the principle of direct thermal mass flow measurement. It offers a standard accuracy rating of ± 2%RD if the flow is higher than 50% of it’s maximum full scale and ±(1%RD + 0.5%FS) on lower flows, flow ratings from 0.2 up to 200 ln/min, and handles pressures up to 10 barg. The MASS-VIEW® incorporates the latest OLED technology, which gives a brighter readout than LCDs, can be viewed from virtually any angle and has fast signal response times. Alarm settings and the selection of a gas/range are accessed via menu. An analog output signal enables data logging against various parameters and full accountability of gas flow.
> Features
Clear indication in:
- actual flow rate (bar graph and value)
- desired flow units
- type of gas
- totalized flow
- Bright, wide-angle OLED display
- Freedom from parallax error
- Virtually independent of pressure and temperature variations
- Low pressure drop
- Wide flow ranges
- Fast response
- High accuracy
- Alarm and counter functions (2 alarm contacts available on meters)
- Analog (0..5 Vdc) and digital communication (Modbus-RTU, RS-232 interface)
- Configurable password protection
- 7 pre-installed gases available (Air, N2, O2, Ar, CO2, CH4, C3H8 or H2 or He)
- 4 selectable ranges (100%, 50%, 25% and 10% of maximum fullscale range)
- Digitally calibrated
- 3 year warranty
|
|
|
Bronkhorst High-Tech developed a field bus based pc-board for their mass flow metering and control solutions featuring self-diagnostics, alarm and counter functions, digital communication and remotely adjustable control settings. The digital "multibus" Mass Flow Meter can be equipped with on-board interface board with DeviceNet, Profibus-DP, Modbus or FLOW-BUS protocol. The newest digital Mass Flow Meters of the Select Series offer Multi Gas / Multi Range functionality featuring greater flexibility for user selection of both flow ranges and gas types, maintaining high accuracy and turndown range for measurement and control. Thanks to this feature users of the Select series can rescale their instruments on site, saving time (and money) for mounting and dismounting. For the convenience of the user, Bronkhorst High-Tech has developed a free and easy-to-use software tool called "FlowTune" for changing the configuration of Select instruments.
|
|
|
|
|
|
The latest product line developed by Teledyne Hastings Instruments is the digital version of the high capacity flow instruments. These new digital instruments allow measurement and/or control up to 10,000 slm. The new line complements the existing lower flow Digital Metaline(R) (5 sccm to 30 slm).
The two product lines, Digital Metaline and the new high capacity digital flow instruments, offer flow meters and controllers from 5 sccm to 10,000 slm, with superior accuracy. The lower flow Digital Metaline units have all-metal seals. A 4µ-inch Ra finish is available for flow rates up to 10 slm. Multiple gas calibrations and stored gas conversion factors are key features that set these instruments apart from the analog versions.
Both the Digital Metaline and the high-capacity digital flow instruments feature flexible operation with ±12, ±15 or 24 VDC power supply and transparent operation in analog or digital modes. All digital units are available with RS232 or RS485 interface with baud rates up to 19.2 kbaud. In addition, the instruments offer convenient self-diagnostics including warnings and alarms for flow, sensor, and valve status.
|
|
|
|
|
|
The latest product line developed by Teledyne Hastings Instruments is the digital version of the high capacity flow instruments. These new digital instruments allow measurement and/or control up to 10,000 slm. The new line complements the existing lower flow Digital Metaline(R) (5 sccm to 30 slm).
The two product lines, Digital Metaline and the new high capacity digital flow instruments, offer flow meters and controllers from 5 sccm to 10,000 slm, with superior accuracy. The lower flow Digital Metaline units have all-metal seals. A 4µ-inch Ra finish is available for flow rates up to 10 slm. Multiple gas calibrations and stored gas conversion factors are key features that set these instruments apart from the analog versions.
Both the Digital Metaline and the high-capacity digital flow instruments feature flexible operation with ±12, ±15 or 24 VDC power supply and transparent operation in analog or digital modes. All digital units are available with RS232 or RS485 interface with baud rates up to 19.2 kbaud. In addition, the instruments offer convenient self-diagnostics including warnings and alarms for flow, sensor, and valve status.
|
|
|
|
|
|
XFM Smart Flow Meter with Optional Profibus Interface
Aalborg® is pleased to introduce the Model XFM, the latest addition to its programmable Thermal Mass Flow Meter line. This low cost "Smart" meter is designed for convenience (it can be programmed remotely), performance (unit stores calibration data for 1-10 gases and conversion factors for up to 32 gases), and accuracy (±1% of FS at calibration temperature and pressure).
The XFM's automatic sensor zero offset adjustment can be activated locally (maintenance push button) or remotely (via digital interface). Digital command technology starts, reads, or saves the current auto zero value.
Additional XFM Features:
Aluminum and stainless steel models.
Digital interface RS485, RS232 (with or without LCD displays), and optional Profibus DP (with I&M functionality).
Programmable Totalizer.
High/Low Flow Alarms
Self-Diagnostic Tests.
23 different Volumetric Flow or Engineering Units.
Internal or user-specific K-factors.
Aalborg®'s XFM Digital Thermal Mass Flow Meters are NIST traceably calibrated and individually programmed.
|
|
|
|
|
|
AALBORG®'s Model DFM MULTI-PARAMETER DIGITAL MASS FLOW METER with Digital Signal Processing provides accurate data on three different fluid parameters: flow, pressure, and temperature.
FEATURES:
- Multi-drop capability up to 256 units (for RS-485 option).
- Stores calibration data up to 10 different gases.
- Supports 10 engineering + user defined units.
- Programmable 12 digit Totalizer indicates total gas volume.
- Flow alarm limits for high & low gas flow.
- Pressure alarm limits for high & low gas pressure with relay output.
- Temperature alarm limits for high & low gas temperature with relay output.
- 4 button keypad & large 128x64 graphical LCD with back light.
- Digital (RS-232 or RS-485) & Analog outputs operate simultaneously.
- Internal conversion factors up to 32 gases.
- Automatic 0 adjustment.
- Self- diagnostics.
INTERFACE:
Features accessed via local keypad & LCD. The digital interface operates via RS485 (RS-232 available) & provides access to internal data including: flow, temperature, pressure reading, auto zero, totalizer & alarms settings, gas table, conversion factors & engineering units selection, dynamic response compensation & linearization table adjustment.
Analog interface provides 0 to 5Vdc, 0 to 10Vdc or 4 to 20 mA outputs for flow, pressure & temperature.
LEAK INTEGRITY:
1 x 10-9 smL/min of Helium maximum to outside environment.
|
|
|
|
|
|
The FMA-1600A and FVL-1600A Series mass and volumetric flowmeters use the principle of differential pressure within a laminar flow field to deterime the mass flow rate. A laminar flow element (LFD) inside the meter forces the gas into laminar (streamlined) flow. Inside this region, the Poiseuille equation dictates that the volumetric flow rate be linearly related to the pressure drop along a fixed distance of the LFE. This, along with the viscosity of the gas, is used to accurately determine the volumetric flow rate. Separate absolute temperature and pressure sensors are incorporated and correct the volumetric flow rate to a set of standard conditions. This standardised flow rate is commonly called the mass flow rate and is reported in units such as standard cubic feet per minute (SCFM) or standard litres per minute (SLM).
Standard units include a 0 to 5 V output (4 to 20 mA optional) and RS232 communications. The gas select feature can be adjusted from the front of the keypad or via RS232 communications. Volumetric flow, mass flow, or absolute pressure, and teperature can be viewed or recorded through the RS232 connection. It s also possible to multi-drop up to 26 units on the same serial connection to a distance of 38 metres. These flowmeters can be powered by the optional battery pack FMA1600-BP for use in the field.
The FVL-1600A Series comprises volumetric flowmeters only. They do not measure or correct for absolute pressure or temperature. The FMA-1600A Series is recommended if the operating pressure is above 10 psig or if there is any restriction or backpressure in the applications.
|
|
Gas Flow Regulators & Switches with LC-Display and Totalizerfunction
Alongside numerous other possible uses, the red-y compact becomes an affordable alternative to the traditional variable area flowmeters.
In addition to its independence from the mains supply the compact series offer a clear and accurate indication of flow, insensitive to pressure and temperature changes, an integrated manual control valve and configurable switch functions.
- First mass flow meter with battery power
- At least two years of autonomy
- CMOS sensor technology
- On-the-spot direct reading, including bar graph
- Extremely compact unit
- Insensitive to pressure and temperature changes
- High accuracy and turndown ratio
- No moving parts
- Resistant to pressure bumps
- No restriction on installation position
- No inlet section required
- Optional 24 Vdc supply, manual valve & switch
- 3-year warranty
|
|
We help you to develop a superior product based on our leading CMOSens® Technology. Together with our customers we have implemented modules and complete devices for the following markets and applications.
In cooperation with our customers we for example developed:
- Digital mass flow controllers
- Battery powered flow meters
- Gas meters
- Flow meters with 200 slm range for medical applications
- Flow meters up to 30'000 slm
- System design with combined flow and pressure control (gaschromatography)
|
|
|
|
|
|
KOFLOC D3810
The KOFLOC Mass Flow Meter MODEL 3810DS SERIES is a low-cost mass flowmeter based on the time-tested MODEL 3810 SERIES mass flow meter, but with a new improved sensor and CPU, resulting in much improved overall performance in accuracy, repeatability and size reduction. The improvement also allows much wider measurement range from as little as 100 cc to 50 L/MIN. Despite its low-cost, the MODEL 3810DS SERIES uses bypass capillary mechanism so it does not sacrifice accuracy.
FEATURES
- Rohs compliance - Compact & Low-Cost - Free mounting position
- Easy maintenance
APPLICATIONS
- Air sampling - Analyzer component - Bioreactor
- Biotechnological process - Burn control - CCFL manufacturing
- Chamber pressure control - Chemical process - Environment monitoring
- Electronic device manufacturing - Food production - Fuel cell testing
- Fermentation process - Gas blending - Gas distribution
- Gas flow monitoring - Gas generation - Industrial furnace
- Leak testing - Pharmaceutical process - Pollution monitoring
- Process flow control - R&D - Solar power element manufacturing
- Secondary calibration reference - Semiconductor process - Sputter deposition
- Surface treatment process - Thermal flame spray - Thin film manufacturing
- Vacuum apparatus - Vapor deposition
|
|
|
|
|
|
Porter 100 Series Mass Flowmeters (MFM’s) accurately measure flow rates of a wide variety of gases from 5 sccm to 1000 SLPM full scale nitrogen flow for operating pressures up to 3000 PSIG. The MFM’s provide a linear flow signal output proportional to a calibrated flow rate.
Porter Digital Series 500 MFM's handle flow rates and operating pressures identical to those of the 100 Series MFM's. The Digital Series 500 MFM's feature better accuracy & repeatability than analog MFM's, performance-enhancing digital electronics, multi-gas capability & self-diagnostics.
Porter 3200 Series MFM's are CSA-certified for Class 1, Division 2, Groups A, B, C and D hazardous locations and provide accuracy, repeatability and response necessary for demanding process applications. Model 3271 is designed to be an integral component in surface-mount fluid distribution systems utilized in process analyzer and sample handling applications. Specifically configured to ANSI/ISA-76.00.02 specifications for surface-mount components, Model 3271 can be installed on two (2) spaces of an SP-76 compliant manifold without the use of process connections. Model 3211 MFM includes compression fitting or metal gasket face seal process connections for inline installation.
|
|
Flow Monitoring
Blue-White manufactures electronic BW DIGI-METER digital flow meters, flow sensors, and flow monitoring equipment; as well as MICRO-FLO Flow Verification Systems.
BW DIGI-METER variations include Rate and Totalizer meters; 4-20mA / 0-10 VDC analog output flow rate and totalizers; Batch Process Controllers; and Hall Output Signal. Both battery and AC powered versions are offered. Many material, calibration and mounting styles are available.
MICRO-FLO variations include: Sensor Only and Panel Mount Display. Units can be mounted to Blue-White metering pumps to verify chemical injection has occurred. Flow units include: Gallons; Liters; Ounces, Milliliters. Time units include: Minutes; Hours; Days.
|
|
|
The rotating movement of the impeller is transferred by a modulator disc to the sensor system of the FLYPPER electronic counter module.
|
|
♦ Displays Rate & Total Simultaneously.
♦ 4½ Digit Rate Display, 8 Digit Totalizer Display.
♦ 4-20mA Analog Output.
♦ Powered From Internal Battery, External DC
Supply or 4-20mA Output Loop.
♦ 10 Pt. Linearization Available.
♦ Isolated Scaled Pulse Output.
|
|
¨ 5 Digit Rate Display, 8 Digit Totalizer Display.
¨ Local Magnetic or Remote Reset.
¨ 4-20mA Analog Output.
¨ Powered From Battery, DC Supply, 4-20mA Output
Loop, or AC Line.
¨ 20 Pt. Linearization Option.
¨ Isolated Scaled Pulse Output.
¨ Alarm Output for Rate or Total.
¨ Windows® Configuration Program.
¨ RS 232 Port for Configuration and Monitoring.
¨ Diagnostics for Pulse, Alarm and Analog output.
¨ Password Protection for Menu and Reset.
|
|
|
With more than a quarter of a million units in operation, in applications around the world, Cameron is the undeniable leader in the design and manufacture of totalizers and flow analyzers. The NuFlo MC Family of Flow Analyzers delivers a broad range of functionality and capability from the straightforward MC-II Totalizer, which provides rate and flow, to the MC-III EXP Flow Analyzer, which utilizes Modbus® communications to download extensive archival logs in less than a minute. The MC Family of Flow Analyzers is ideal for use with Cameron's comprehensive line of turbine meters and performs equally well with all turbine brands on the market today.
|
|
|
Flow products are used in a variety of applications where liquid or gas flow needs to be monitored or controlled. In many processes, both the total quantity of product being produced and the rate at which the product is being produced must be known; flow controllers can offer that information while monitoring your process efficiency.
|
|
