Idecode - Compact Fitting - Plastic - Type SPC
Universal fitting - established 22mm fixing footprint suitable for most general applications. Withstands environments where high humidity or hose down is required. Durable polyester housing. Wide 14mm Sensing and high tolerance to misalignment. Up to EN 954-1 Cat.4 with safety relay. 2NC 1NO circuits. Quick connect versions.
Part No Type Cable Length Circuits
111001 Idecode SPC 2M 2NC
111002 Idecode SPC 5M 2NC
111003 Idecode SPC 10M 2NC
111004 Idecode SPC QC-M12 2NC
111005 Idecode SPC 2M 2NC 1NO
111006 Idecode SPC 5M 2NC 1NO
111007 Idecode SPC 10M 2NC 1NO
111008 Idecode SPC QC-M12 2NC 1NO
|
|
Idemag - Magnetic Non Compact - Type MPR
Compact yet robust fitting suitable for all small guard applications. Can be mounted unobtrusively in channels or behind doors - left or right cable exit Hygienic screw cap covers ensure suitability for Food Processing washdown Cost effective interlock solution Wide sensing at 12mm and high tolerance to misalignment High current switching capability to 0.5A. 2NC 1NO circuits - up to EN 954-1 Cat.4 with Safety Relay
Part No Type Cable Length Circuits
114001 MPR Cable Right 2M 2NC
114002 MPR Cable Right 5M 2NC
114003 MPR Cable Right 10M 2NC
114004 MPR Cable Right QC-M12 2NC
114005 MPR Cable Right 2M 2NC 1NO
114006 MPR Cable Right 5M 2NC 1NO
114007 MPR Cable Right 10M 2NC 1NO
114008 MPR Cable Right QC-M12 2NC 1NO
114009 MPR Cable Left 2M 2NC
|
|
|
|
|
|
IDEM has launched The Kobra 'Hygiecam' KL3-SS , the world's first Solenoid Locking Tongue Interlock Switch in a fully Stainless Steel 316 housing. The switch has a mirror polished finish and is designed to cope with the rigorous high pressure hose cleaning demands of food and beverage manufacturing industries.
The KL3-SS is a compact, slimline locking switch designed to fit to all general applications.
The housings are IP69K rated and provide guard locking for medium to heavy duty guards (up to 3000N.).
The head is rotable to provide 8 actuator entry positions and all fittings including the actuators are made from Stainless Steel 316 to provide tough mechanical and environmental durability.
The switch is released by applying power to the solenoid after the machine is stopped.
A uniquely designed mechanism means that 2 sets of positively driven contacts are provided to monitor the actuator position and the solenoid status independently.
4NC Safety and 2NO auxiliary circuits are provided plus there are 2 LED's to provide independent diagnostics for the solenoid status and the actuator lock status.
|
|
Idem Safety Switches have launched the first fully Stainless Steel 316 Universal Tongue Interlock switch to cope with the rigorous demands of the food, beverage and pharmaceutical environments.
The Kobra K-SS has a universally established industry footprint suitable for most general applications and is suitable were high humidity or chemical washdown is required e.g.Food and Beverage Processing and Petro-Chemical Industries. The housings are IP69K rated and are suitable for CIP cleaning and high pressure hosing.
Features:
Fully Stainless Steel 316 housing - double seal gasket
IP69K enclosure protection - High Temperature 100C. Hose Down
Universal fitting - established footprint suitable for most general applications
60 mm wide 100 mm long
4 pole contact blocks - (replaceable)
Head can be rotated to give 4 actuator entry positions
Standard or Flexible actuators
|
|
Tongue - Interlock Safety Switch - Type IDIS-1
Positive opening safety contacts to IEC 947-5-1 Compact version - fits on 22mm hole centres EN 50047 body Head position adjustment to give 8 actuator entry positions High Mechanical Life 1,000,000 cycles Enclosure Protected to IP 66/67 - washdown suitable Conduit entries: M20 ½" NPT or Quick connect
Part No Type Contacts Fittings
190001 Angled Actuator 2NC 1NO M20
190002 Angled Actuator 2NC 1NO 1/2" NPT
190003 Angled Actuator 2NC 1NO QC
190004 Flat Actuator 2NC 1NO M20
190005 Flat Actuator 2NC 1NO 1/2" NPT
190006 Flat Actuator 2NC 1NO QC
190007 Plastic Flex Actuator 2NC 1NO M20
190008 Plastic Flex Actuator 2NC 1NO 1/2" NPT
190009 Plastic Flex Actuator 2NC 1NO QC
|
|
Safety Switches with Solenoid Interlocking and Interlock Monitoring TZ
The TZ safety switch has a magnetic locking device with additional interlocking monitoring. Consequently, the position of the door and the magnets can be monitored by the higher-ranking control. TZ type safety switches are type 2 switches. They differ by the type of interlock, magnet operating voltage, actuating head, contact elements used as well as the type of connection.
Features
Mechanical unlocking mechanism from the front side
2 LEDs for function display
Optionally with emergency release
Connection by cable routing or plug connector
Max. 8 contact elements permit flexible wiring
|
|
Idem has launched the Kobra KP Range of Universal Tongue Interlock switches to cope with the rigorous demands of the food, beverage and pharmaceutical environments.
The Kobra KP Tongue Interlock Switch has an established footprint suitable for most general applications. High specification materials means it is suitable for use in rigorous areas were high humidity or washdown is required e.g.Food Processing and Petro-Chemical Industries.
ATEX Explosion Proof versions are available.
The Rotatable Head means it can easily be fitted to the leading edge of Hinged, Sliding or Lift off Guard Doors, and the unique double seal gaskets ensure reliability sealing against moisture ingress. All external and intern al screw fittings are Stainless Steel. 3 or 4 pole contact blocks are available and can be upgraded or replaced without removing the switch from the application.
4 different actuators are available including Flexible versions to help with alignment.
|
|
|
|
|
|
The company Pizzato Elettrica is suggesting to the market many new products in the safety field for the factory automation.
In particular, it has been recently introduced anew and innovative series of strong safety switches with separate actuator and solenoid for guards and entrance machinery monitoring.
These FG series switches have a shape suitable for the installation also on modular profiles (40x40 mm) and distinguish themselves for following features:
- High sturdiness guaranteed by the metal housing and the stainless steel actuator (holding force 2500 N)
- Contact blocks with 4 poles available in 12 different configurations.
- Possibility of operation state signalling through external LED.
- Rotating head in 90° steps, not detachable, with actuator entries both frontal and vertical for the maximum versatility in the installation
- Protection degree IP67
- Versions with rotating lock release device, with emergency release push button or with both devices.
The new switches series integrates the wide range of products that Pizzato Elettrica can offer to its customers, for complete solutions and without compromise to machinery safety problems.
For further information it’s possible to visit the web-site www.pizzato.com or ask for the new general catalogue 2007/2008.
|
|
|
Omron STI safety interlock switches are available in a wide variety of models to satisfy most machine guarding applications. Models range from rope-operated emergency stop switches, non-contact magnetic and hinge-pin-operated interlocks, to solenoid-actuated guard-door locking switches that restrict access until safe conditions exist. All models conform to applicable U.S. safety standards and all carry the CE mark.
|
|
|
|
|
|
Door interlock switches are attached to the door of equipment where it is necessary to turn power on or off when the door is closed or opened. This type of control is used in applications where maintenance and testing must be performed inside a cabinet.
Interlock switches are supplied with one 1PDT snap action switch or two 1PDT miniature snap action switches.
The snap action switches are mounted in a frame and a single actuator, which is spring loaded, operates the switch.
When mounted in a door, the closing of the door forces the actuator against the spring thereby closing the switch.
When the door is open, the actuator springs out thereby opening the power circuit. The interlock switch has a service position, which allows service personnel to turn power on even when the cabinet door is open. When the door is closed, the switch automatically resets to the normal closed position.
Ratings:
See selection table.
Operating Features:
Free position - 9.53mm (.375²) max.
Operate position - 5.12mm (.203²) max.
Depressed position - 3.17mm (.125²) max.
Materials and Finishes:
Switch - Contact Eaton Customer Service.
1-800-962-0820
Bracket - Stainless steel.
Actuator - 1 Pole - Molded noryl; 2 Pole - stainless steel.
Spring - Stainless steel.
Insulator - Glass cloth.
Mounting:
Tapped holes are provided for mounting in either of two positions - 2 screw side or front panel mounting.
Mounting hardware is not provided.
Options:
Special circuits.
Solder lug, spade, and PC terminations.
Special actuators.
Approvals:
UL Recognized.
CSA Certified.
|
|
|
The 100 Series are non-contact interlock position switches with switching voltage models available up to 250 Volts. There are many models to fit a wide variety of applications.
|
|
Guard Locking Tongue Switch - Type KLM
Designed to fit to hinged or sliding guards to provide high mechanical holding force and safety interlocking where it is required to protect the operator from moving machinery.
A unique internal mechanism design provides up to 4NC 2NO contacts and provides independent monitoring of the locking mechanism and the tongue position.
2 LED's provide Status of the Solenoid and Door Locked
Can be used with a Safety Relay to provide EN954-1 Cat.4 protection.
Rugged Die Cast housing - IP67 enclosure protection and optional Stainless Steel Head.
Provides Guard Holding up to 3000N (300Kg)
Spring to Lock - Solenoid operate to release
Conduit entry M20 or ½" NPT
Solenoid Voltages available: 24V. ac/dc 110V.ac 230V.ac
Flexible actuator available.
|
|
| ... products without technical information |
| |
Explosion Proof Switches - Type KP-Ex
Safety Switches with positively operated ATEX Eexd llC T6 certified explosion proof blocks.
Part No Type Pre-wired cables Contacts
200016 Kobra KP-Ex 1 x 3m. 4 core 1NC 1 NO
200019 Kobra KP-Ex 1 x 3m. 4 core 2NC
|
|
|
|
|
|
IDEM has launched The Kobra 'Hygiecam' KL3-SS , the world's first Solenoid Locking Tongue Interlock Switch in a fully Stainless Steel 316 housing. The switch has a mirror polished finish and is designed to cope with the rigorous high pressure hose cleaning demands of food and beverage manufacturing industries.
The KL3-SS is a compact, slimline locking switch designed to fit to all general applications.
The housings are IP69K rated and provide guard locking for medium to heavy duty guards (up to 3000N.).
The head is rotable to provide 8 actuator entry positions and all fittings including the actuators are made from Stainless Steel 316 to provide tough mechanical and environmental durability.
The switch is released by applying power to the solenoid after the machine is stopped.
A uniquely designed mechanism means that 2 sets of positively driven contacts are provided to monitor the actuator position and the solenoid status independently.
4NC Safety and 2NO auxiliary circuits are provided plus there are 2 LED's to provide independent diagnostics for the solenoid status and the actuator lock status.
|
|
Idem Safety Switches have launched the first fully Stainless Steel 316 Universal Tongue Interlock switch to cope with the rigorous demands of the food, beverage and pharmaceutical environments.
The Kobra K-SS has a universally established industry footprint suitable for most general applications and is suitable were high humidity or chemical washdown is required e.g.Food and Beverage Processing and Petro-Chemical Industries. The housings are IP69K rated and are suitable for CIP cleaning and high pressure hosing.
Features:
Fully Stainless Steel 316 housing - double seal gasket
IP69K enclosure protection - High Temperature 100C. Hose Down
Universal fitting - established footprint suitable for most general applications
60 mm wide 100 mm long
4 pole contact blocks - (replaceable)
Head can be rotated to give 4 actuator entry positions
Standard or Flexible actuators
|
|
Tongue - Interlock Safety Switch - Type IDIS-1
Positive opening safety contacts to IEC 947-5-1 Compact version - fits on 22mm hole centres EN 50047 body Head position adjustment to give 8 actuator entry positions High Mechanical Life 1,000,000 cycles Enclosure Protected to IP 66/67 - washdown suitable Conduit entries: M20 ½" NPT or Quick connect
Part No Type Contacts Fittings
190001 Angled Actuator 2NC 1NO M20
190002 Angled Actuator 2NC 1NO 1/2" NPT
190003 Angled Actuator 2NC 1NO QC
190004 Flat Actuator 2NC 1NO M20
190005 Flat Actuator 2NC 1NO 1/2" NPT
190006 Flat Actuator 2NC 1NO QC
190007 Plastic Flex Actuator 2NC 1NO M20
190008 Plastic Flex Actuator 2NC 1NO 1/2" NPT
190009 Plastic Flex Actuator 2NC 1NO QC
|
|
Guard Locking Tongue Switch - Type KLM
Designed to fit to hinged or sliding guards to provide high mechanical holding force and safety interlocking where it is required to protect the operator from moving machinery.
A unique internal mechanism design provides up to 4NC 2NO contacts and provides independent monitoring of the locking mechanism and the tongue position.
2 LED's provide Status of the Solenoid and Door Locked
Can be used with a Safety Relay to provide EN954-1 Cat.4 protection.
Rugged Die Cast housing - IP67 enclosure protection and optional Stainless Steel Head.
Provides Guard Holding up to 3000N (300Kg)
Spring to Lock - Solenoid operate to release
Conduit entry M20 or ½" NPT
Solenoid Voltages available: 24V. ac/dc 110V.ac 230V.ac
Flexible actuator available.
|
|
|
|
