The SLTE is freely positionable and has a precision, sturdy guide. Motors with an integrated encoder are available as the drive. For working loads up to max. 4 kg and fast positioning times (50 mm in approx. 400 ms).
Based on the design platform of the SLT, the SLTE provides practically the full range of interfaces as well as full compatibility with the modular handling and assembly system including adapter kits.
- Sizes 10 and 16 mm
- Strokes from 50 ... 150 mm
- Max. speed 170 to 210 mm/s ( with size 10/16)
- Repetition accuracy < 0.1 mm
|
|
NCBM
The NCBM stage system consists of extremely rigid aluminium section, a MONORAIL BM as well as a ball-screw drive and is suitable for measurements, tests or machining processes with travels of up to 1500 mm. MINORAIL BM guides can be optionally fitted with an integral AMSA measurement scale.
|
|
We offer a range of linear axes delivered without motorization, but with adaptation motor:
- Guides with ballscrew Type 308
=> 4 sizes (rods Ø12 to 25 mm)
load 40 kg max. , stroke 400 mm max.
- Module with rack Type 832
=> 1 size (rods Ø16 mm)
load 5 kg max. , stroke 320 mm max.
- Units with linear motion rolling guide for linear motors
=> contact us
|
|
|
Linear axis at 2 axis, with traction with belt and rack, with predisposition for the mounting of gearboxes
|
|
The linear modules Super Wide Body Line provides a self-supporting frame to be easily integrated into the customer’s systems.
They are made of solid aluminium alloy profile with linear guide function.
A special treatment makes the rails’ surface hard like the hardened steel.
The sintered plastic compound of the roller lining resists to pollutants and preserve the rail from wear.
The combination hard alloy of the rails and plastic lining of the rollers provides a very silent running and a very long life (that is several years).
The bearings of the rollers can be life-time lubricated or equipped with lubricator (see catalogue).
The movement is activated through timing belt.
The standard accessories enable an easy and quick connection with motors and columns. Versatility, high competitive performances and prices are the key features of our Super Wide Body Line range.
|
|
|
All electrical cylinders and linear axes / robots are available as clean room (ISO cleanliness class 4) and dust-/waterproof (IP54/IP65/IP67) types, too.
|
|
Parallel cylinder
for high loads and moments in every direction double action force
Technical Information:
· Designed flat and with double force, the Parallel cylinder with central port on the special end caps does also absorb higher forces. The yokes are aligned true a plate
· The load can be multiplied and the action force doubled by adjusting two rodless pneumatic cylinders parallel.
· The parallel cylinder can overall be used where big parts must be moved, e.g.
- workpieces on machining centers
- assembling machines
- transport systems
- stroke systems with limited adjusting length
· Port rotatable in the middle and upwards, inand outside
· Cushioned end positions are adjustable
|
|
|
|
|
|
With the eLINE eCKK and eCKR Compact Modules, Rexroth has considerably simplified selection, assembly and above all start-up for users.
The stepping motor, already mounted, with positioning control has 16 freely programmable positions. For easy start up of the axis an easy-to-use communication software (download under construction) and pre-configured parameter files are available for download. By means of digital inputs, the eLINE Compact Module communicates with higher-level control systems. The axes also work in stand-alone mode without an additional PLC. The user operates the linear systems manually in jog mode and can enter destination positions easily using a Teach function.
The eLINE eCKK Compact Modules with eLINE Ball Screw Assemblies and the eCKR with a toothed belt have exactly the same main dimensions and connection dimensions as the well established standard Compact Modules from Rexroth. The predefined raster lengths with clearly assigned order numbers simplify the selection from the numerous strokes and lengths.
Two integrated back-lash free eLINE Ball Rail Systems ensure optimum running of the carriage. In hybrid technology, they combine the advantage of the low weight of aluminum with the hardness of the steel running surfaces admitted. The eLINE Compact Modules thus combine high traversing speed with high precision and low running noise over lengths of up to 1,440 mm.
The eLINE Compact Modules in size 90, lubricated for the duration of their usable life, move workpieces with a weight of up to 15 kg.
|
|
Linear modules
SA/6
From the flexible positoning up to the exact measurement. That are application examples of the high dynamic, precise and compact linear modules.
|
|
Linear axis´s »MINI«
"Mini" linear axes are available with belt or spindle drives. Carriages are guided by means of rollers on guides mounted in the base profile. The stable and compact construction enables highly dynamic movement to be achieved within the load range. Servo motors are generally used for the drive but other forms of motorisation are possible. Axes can be supplied with a stroke of up to 6 m.
|
|
Rigid design on the basis of cast solid carriage and closed aluminum shaped.
Basic section: 40x40 - 60x 60 - 90x70
Load capacity: 300kg
Maximum speed: 5m/s
Maximum acceleration: 25 m/s ²
5 possibilities:
·Horizontal axis with belt
·Vertical axis with belt
·Vertical axis with belt with balancing of pneumatic load
·Pneumatic horizontal axis
·Horizontal axis with ball screw
·Guide pin
Our axes are provided with the flask of adaptation, reducer and driving coupling.
Many accessories of connection for the realization of multiple combinations
|
|
Linear axles and linear oh systems
The company Romani offers a large assortment at linear axles and linear oh systems different considerable manufacturer.
The linear axles are propelled available by Kugelgewindetrieb, toothed belt or pneumatic cylinder, in different dimensions and modifications in aluminum or steel.
A large accessory assortment, like mounting plates, transmissions and engines, supplements the program. Short delivery times are made possible by the modular structure.
Whether for very precise, it snaps or the optimal linear unit arranged high-dynamic tasks, noiseless or particularly economical solutions, it for each application.
|
|
|
|
|
|
With the eLINE eCKK and eCKR Compact Modules, Rexroth has considerably simplified selection, assembly and above all start-up for users.
The stepping motor, already mounted, with positioning control has 16 freely programmable positions. For easy start up of the axis an easy-to-use communication software (download under construction) and pre-configured parameter files are available for download. By means of digital inputs, the eLINE Compact Module communicates with higher-level control systems. The axes also work in stand-alone mode without an additional PLC. The user operates the linear systems manually in jog mode and can enter destination positions easily using a Teach function.
The eLINE eCKK Compact Modules with eLINE Ball Screw Assemblies and the eCKR with a toothed belt have exactly the same main dimensions and connection dimensions as the well established standard Compact Modules from Rexroth. The predefined raster lengths with clearly assigned order numbers simplify the selection from the numerous strokes and lengths.
Two integrated back-lash free eLINE Ball Rail Systems ensure optimum running of the carriage. In hybrid technology, they combine the advantage of the low weight of aluminum with the hardness of the steel running surfaces admitted. The eLINE Compact Modules thus combine high traversing speed with high precision and low running noise over lengths of up to 1,440 mm.
The eLINE Compact Modules in size 90, lubricated for the duration of their usable life, move workpieces with a weight of up to 15 kg.
|
|
|
Pico series robots are single axis robots using a program-less controller PRC. While priced at a low level, each robot has various functions such as thrust control and zone signal output. It is also designed for great ease of use.
|
|
Drive timing belt - Guidance shoes + double rails
Drive ball screw - Guidance shoes doubles rails
Drive timing belt - Guidance shoes doubles rails
Drive ball screw - Guidance shoes doubles rails
Drive timing belt - Guidance shoes doubles rails
Drive ball screw - Guidance shoes doubles rails
|
|
Robot tracks
Advantages:
- combination of 6-axis robot with state of the art linear module
- precise, hardened LM guides, or hardened flat bar
- high stiffness achieved by steel construction
- high flexibility in handling of parts
- excellent value for money
Technical characteristics:
- hardened, play free LM guides in size 35 - 55 or hardened flat bar
- hardened rack and pinion drive
- felt pinion for lubrication of the rack
- central lubrication system for complete axis
- repeatability less ± 0.1 mm
- easy floor adjustment
- driving speed over 2m/sec
- with covers on request
|
|
This is the enhanced 2nd generation of IAIs most polular series of linear actuator. The series incorporates a number of major design innovations which have greatly enhanced the capability of our ballscrew actuators.
Increased overall rigidity and frame strength
- Minimised overall length and smaller footprint
- AC servo motor with optical encoder
- Four different sizes
- Low, medium and high speed type
- Maximum stroke : 2,500 mm
- Maximum horizontal payload : 150 kg
- Maximum speed : 2,000 mm/s
- Repeatability : +/-0.05 mm ("P" precision design: +/-0.02 mm)
|
|
| ... products without technical information |
| |
Parallel cylinder
for high loads and moments in every direction double action force
Technical Information:
· Designed flat and with double force, the Parallel cylinder with central port on the special end caps does also absorb higher forces. The yokes are aligned true a plate
· The load can be multiplied and the action force doubled by adjusting two rodless pneumatic cylinders parallel.
· The parallel cylinder can overall be used where big parts must be moved, e.g.
- workpieces on machining centers
- assembling machines
- transport systems
- stroke systems with limited adjusting length
· Port rotatable in the middle and upwards, inand outside
· Cushioned end positions are adjustable
|
|
|
|
|
|
Linear Motor Table LT is a direct drive positioning table featuring a low sectional height and light weight. An AC linear servo motor and an optical linear scale are compactly integrated in the moving table and bed made of aluminum alloy, and miniature type linear motion rolling guides IKO Linear Way L are assembled in the table guide section. Linear Motor Table LT, adopting a C-shaped magnet yoke arranged in-between two stator magnets together with a moving coil, provides large driving force and achieves high speed and quick response positioning. Linear Motor Table LT is most suitable for applications requiring high speed operation such as semi-conductor and liquid crystal related equipment, measuring instruments, assembling systems, material transfer equipment.
Features:
Maximum thrust 900N for high thrust series
Compactness and high thrust were pursued by adopting miniature optical linear scale and C-shaped magnet yoke. Maximum thrust 900N is achieved by high-density coil arrangement. Also, compact series output 450N with the total height only 40mm
High acceleration and high response with a smooth motion
High acceleration and high response positioning can be made due to super light weight moving table and high thrust. The table can travel with a smooth motion by using C-shaped magnet yoke which cancels out magnet forces and eliminates the unnecessary load on the linear motion rolling guides. Also, C-Sleeve Linear Way, long term maintenance free type, is adopted for their linear motion rolling guides.
High resting stability and speed stability
High resting stability is achieved by the latest servo technology. This linear motor can be used as a high accurate positioning device. Also, high speed stability is achieved.
|
|
The SR stage is a compact, small footprint, open type positioning stage. It is used in closed loop positioning applications that require high speed and high accelerations of lighter loads.
The ironless core coil assembly has no magnetic attractive force to the stationary magnet assembly, which reduces the load on and increases life of the bearing system.
The low overall weight of the stage makes it ideal as a Y axis (top axis) in a multi-axis system. The lower moving mass of the stage allows for much higher accelerations of light payloads.
The cable carrier is oversized to allow for passage of customer payload cables and hoses. The back of the cable carrier can be easily removed and reattached to route through additional cables.
|
|
| ... products without technical information |
| |
|
|
|
|
Technical Specifications
Number of axes: 5
Axes Stroke: 7.000mm x 2.000mm x 600mm
Pallet Dimensions (mm): 3000x2000 / 6000x2000
Rapid feeds (n/min.): 70,0
Rotary table - number of positions: 2
Tool change: HSK A63 / HSK A80 / HSK A100
Max torque (Nm): 231/231/231
Power (Kw): 78,0/78,0/78,0
Spindle rotation speed: 20.000/20.000/18.000
Linear axes measuring system: pressurized Heidenhain optical scales
Rotating axes measuring system: Encoder Heidenhain
Tilting head: Yes
Tilting table: Yes
General description
In recent years the winning card in MCM's products has been high speed, applied to all types of material, from aluminium to titanium.
One of its showpieces in this field is the JET FIVE solution. The barycentre-axis driven structure combines top speed with extreme precision and rigidity. The machine structure design with one-piece beam upright provides rigidity 8 times higher than traditional solutions.
The main characteristics of this linear motor work center are: high performance, acceleration, speed, thermo-symmetrical structure, drastic reduction in wear and tear, high rigidity, compactness, flexibility and even more. The machine has a horizontal carriage and is made of arc-welded steel, designed for maximum rigidity and minimum weight.
|
|
Ultra High Speed Vertical Linear Motor Machines LX Series
LX-0
The LX-0 is ideally suited to industry sectors where ultra high speed and exceptional high accuracy are the minimum requirement.
LX-0 5AX
By utilizing Direct Driven Linear Motors on the ntegrated 5 axis table, the LX-0 5AX offers users all of the LX-series technology in a 5 axis format.
LX-1
With Linear Motors on all axes, the LX-1 offers users unprecedented levels of high accuracy, ultra high speed productivity.
|
|
The AZ 150 is a high-accuracy and high-efficiency vertical machining center to mill molds or small-sized-parts with nano level accuracy.
Being equipped with counter balance axes to control vibration and also the change of weight position, th AZ 150 can perform excellent and high-accuracy machining for both surface finish and profiles.
|
|
| ... products without technical information |
| |
M5 - LINEAR DRIVE , It's a new VERTICAL MACHINING CENTER TRAVELLING COLUMN with linear motor Fanuc on X axe.
This machine can be used also in pendular configuration permitting maximum capabilities as well as a X axis travel of 875 mm on both working area.
Moreover, the ‘M5’ machine is equipped with two indipendent tool storages having 30 tools capacity everyone.
X axis travel 2.200mm
Y axis travel 600 mm
Z axis travel 640 mm
Table Working surface 2400x600 mm
Max loading capacity 6000Kg
Electro-spindle speed 12000 rpm (15000-24000 opt)
Max electro-spindle power for 30 min/continuous 35 - 22.5 kW
Max electro-spindle torque 120 Nm
Axes characteristcs Rapid feedrate (x-y-z) 60 m/min
Work feedrate (x-y-z) 60 m/min *
|
|
KX The Classic HURON
As far back as 1993, Huron presents a very innovating concept of high speed multiaxes machines. KX milling centres have been launched in 1998, portal type and mobile table with 3 axes.
Applications concerned are moulds, cutting tools and machining of models, prototyping and complex pieces.
These machine-tools allow an important swarf removal in roughing, a very high precision in contouring and a high quality in surfacing.
KX 10
XYZ 1.000 / 700 / 550 mm
1.250 x 700 mm / 1.500 kg
18.000 rpm - 35 kW - 120 Nm
XY = 30 m/min - Z = 18 m/min
|
|
|
|
