CIR-e3 PORTABLE ENERGY AUDIT ANALYZER
Most portable analyzers in the market require highly complex parameter establishing processes and start-up procedures.
CIR-e3 has been designed to facilitate the configuration and execution of electrical parameter measurements and, as a consequence, the analysis of energy audit studies.
Applications:
•Energy audits in installations.
•Preventive control and maintenance of transformer substations.
•Subcontracting energy audits.
|
|
|
|
|
|
As a response to the measurement requirements for any distribution and control board, CIRCUTOR has developed a new electrical power analyzer for three-phase systems: CVM-MINI.
Of course any equipment can measure the main parameters in electrical systems, but the smaller size of the three module, DIN analyser, combined with a large number of advantages, make the CVM-MINI the best option for measurement and energy control solutions:
-Capacity to process more than 213 electrical parameters.
-DIN rail mounting or panel mounting (72X72) using an adapter.
-RS485 communications with Modbus/RTU protocol.
-Easy to build into existing control systems.
-Programming, measurement, recording and control software.
-Universal power supply
CIRCUTOR has built into one single small piece of equipment, the performance of any instrument found on any distribution and control board (protection boards, motor and pump control, overload and earth leakage distribution boxes, etc.), in a size and price which will make any board, no matter how small, be incomplete without the presence of the CVM-MINI.
|
|
|
|
|
|
|
COMBI420 is an innovative meter designed to perform all safety test verifies on electrical installations in compliance to recently standards (VDE0100, BS7671 and so on, measure and save results of environmental parameters (illuminanance, temperature), leakage currents and active power, harmonics, power factor measurements on single phase systems. The meter it's very easy to use and have a wide number of internal features which are selectable by using the multilanguage menu. The instrument permits, moreover, to start principal measures by using a special remote prove (PR400 optional accessory) particular useful to perform tests in very quickly mode and the AUTO internal function to perform sequential measurements of Global Earth Resistance, test on RCDs' and Insulation directly on sockets of civil installations. A contextual help menu selectable by user it's available for each measurement function and permits a valid information during connection of meter to the installation. The newest electronic function selector give to the meter a extreme rugged structure for perfect using "on field". A wide internal memory permits the saving of any measurements and the transfer to PC by serial port with dedicated software it's possible. Each measure it's saved with all the sub-results and test parameters with up to two ID locators (selectable by user on meter) in order to reach the exact point where the measure was performed.
|
|
|
|
|
|
The UPM315 is a multifunction metering DIN96x96 device with advanced functionality features, suitable for electrical parameters measurement and power quality analysis.
Main features:
- DIN 96 & ANSI 4” Cutout for New or Retrofit Panels
- Highly Sofisticated Power Meter Providing Advanced Functionality Features
- Large Graphic LCD Display with Excellent Visibility
- Up to Two Plug-In Options
- THD Even, Odd and Individual FFT Harmonic Analysis up to 50th Order
- Power and Current Demand Calculation
- On-Board Memory up to 2MB
- Programmable Min/Max & Energy Data Logging
- Event and Alarm Recording, Waveform Capture, Waveform Display, Phasor Diagrams, Historical Trending, Time-of-Use and more....
The UPM3080 is a multifunction metering DIN144x144 device with advanced functionality features, suitable for electrical parameters measurement and power quality analysis.
Main features:
- Fully Bi-Directional Four Quadrant Readings
- Neutral Current Measurement
- Large Graphic LCD Display with Excellent Visibility
- Up to Two Plug-In Options
- Infrared Communication Port
- THD Even, Odd and Individual FFT Harmonic Analysis up to 50th Order
- Power and Current Demand Calculation
- On-Board Memory up to 2MB
- Programmable Min/Avg/Max and Energy Data Logging
- Event and Alarm Recording, Waveform Capture, Waveform Display, Phasor Diagrams, Historical Trending, Time-of-Use and more....
|
|
The UPM6100 is a portable analyser suitable for electrical parameters measurement on single- and three-phase systems, as well as on direct current systems.
Main features:
- 4 MB Removable Memory Card for Data Logging
- Integrated Printer (Option)
- Large Graphic LCD Display with Excellent Visibility
- Graphic Representation of Voltage and Current Waveforms, Harmonic Spectrum and Phasor Diagrams
- FFT Harmonic Analysis up to 50th Order
- Sags and Swells Detection
- Power and Current Demand Calculation
- Compact and Rugged Case Carrying Accessories
- UL Listed Under UL61010B-1 and CAN/CSAC22.2 No.1010.1-92, File #E231725
- Dedalo Software Included
|
|
|
|
|
|
The MC 760 network analyzer is used for permanent analysis of electric voltage quality in compliance with the SIST EN 50160 standard. Records are stored in the internal memory for the period of the last 7 years. Moreover, more than 170,000 deviations of the measured quantities from the standard values are stored, which enables finding of eventual reasons for the problems on network. Optional limits and required quality in a monitored period can be defined for each monitored characteristic.
The meter measures and records the following characteristics:
Frequency deviations
Voltage deviations
Voltage clips
Voltage interruptions
Voltage unbalances
Over-voltages
Fast voltage changes
Flicker intensity
THD
Harmonics
Features:
Evaluation of the quality of electric voltage in compliance with SIST EN 50160
Measurements of instantaneous values of more than 140 quantities (U, I, P, Q, S, PF, PA, f, ö, THD, MD, energy, energy price by tariffs, etc.)
Accuracy class 0.5 or 0.2 (on demand)
Harmonic analysis of phase, phase-to-phase voltages and currents up to the 63th harmonics
Recording up to 32 measured quantities and alarms in the internal memory (8 MB flash)
Measurements of 40 minimal and maximal values in different time periods
32 adjustable alarms
Wide frequency range from 16 Hz to 400 Hz
RS 232/RS 485 communication up to 115,200 bit/s or Ethernet communication
MODBUS and DNP3 communication protocol
Up to 4 inputs or outputs (analogue outputs, pulse outputs, alarm outputs, tariff inputs)
Universal or AC power supply
Automatic range of nominal current up to 5 A and nominal voltage up to 500 V
Multilingual support
User-friendly PC MiQen software
|
|
MCA Plus network analyzer is an electronic instrument which allows the measurement of 48 main parameters in the input network in real value and RMS value.
It is specially designed for easy installation and programming. It needs three voltage signals (RST) and current (I1, I2, I3).
MCA Plus is supplied with LCD screens backlighted for an easy reading at any lighting level. It offers optional communication module and has internal memory.
|
|
Designed for verification and maintenance departments in industrial or administrative buildings, the Qualistar C.A 8334 enables the user to obtain an instant picture of the main characteristics of electrical network quality.
Handy and very compact, this instrument also gives numerous calculated values and several processing functions in line with current standards: EN 50160, IEC 61000-4-15, IEC 61000-4-30, IEC 61000-4-7.
|
|
|
Portable network analyzer PNA 760 is used for field measuring of different electrical quantities. Using PNA 760 you can easily and quickly find out if electrical voltage complies with EN 50160 standard. It is equipped with numerous accessories for voltage, current measurement and data transfer through various interfaces.
|
|
|
|
|
|
In view of the growing number of factors with a disturbing influence on power systems and the ever increasing sensitivity of the devices and installations on the consumer side, simple monitoring criteria such as undervoltage or overcurrent are usually inadequate nowadays. Reliable logging of all the relevant events within the electrical power system calls for the constant observation of a wide variety of derived parameters such as harmonic content, system unbalance or interharmonics and the swift identification of the slightest deviation from the standard state.
In addition to providing pure monitoring functions, modern power system analysing equipment should be capable of logging in full the mode of operation and the interaction of all the component parts of a power supply system.
Only comprehensive and continuous monitoring of the entire power system enables all resources to be used purposively and effectively for the restoration of system operation should a disturbance occur.
In addition, the recorded data provides the planners of electrical installations and protection equipment with an invaluable basis for the extension and optimisation of primary and secondary equipment.
If you are not already convinced of the importance of using a modern power system monitor, you certainly will be as soon as you are confronted with the question of who is liable for system disturbances and who is responsible for meeting the costs involved.
|
|
Your VNA provides you with the most accurate measurements only if calibrated against known standards. Pasternack VNA Calibration Kits and Tools incorporate accurate, stable, and precise calibration standards designed for a broad range of vector network analyzers models, including Agilent and Anritsu products.
The 3.5mm Standard and N-Type Standard Calibration kits are designed for use with a broad range of vector network analyzers (VNAs) that utilize a Short-Open-Load calibration technique. With the kits you can make error-corrected measurements of devices supplied with either 3.5mm or SMA connectors from DC to 26.5 GHz, or from DC to 11 GHz for N-type connectors. The kits contain both Male (Plug) and Female (Jack) connector interfaces to perform full Two-Port error corrections.
FEATURES:
- Broad VNA Coverage, Including Agilent & Anritsu
- Open, Short, Fixed Broadband Load Configurations
- DC to 26.5 GHz
- In-Series Phase Matched Adapters Available
|
|
| ... products without technical information |
| |
|
|
|
|
The SATEC ezPAC SA300 Power Intelligence Unit is an advanced power analysis and control device unmatched in the utility and industrial environments. The ezPAC unites advanced control and automation functions, intelligent fault-recorder, power quality and sequence of events (SOE) with automatic analysis and reports. It also offers revenue metering, back-up protection equipment and control devices to provide a complete solution for substation and industrial automation.
FAULT RECORDER
- Up to 150A fault currents
- Fault distance calculations
- Up to 48 fast (1 ms) digital inputs
- Sequence of events with 1 ms accuracy
EVENT/DATA LOG
- Up to 57 channel simultaneous recording
- Built-in 4 Mb logging memory, up to 128 Mb (option)
MULTI-TARIFF REVENUE METER
- IEC 62053-22 class 0.2S
ADVANCED POWER QUALITY ANALYSIS
- IEC 61000-4-30 Class A power quality
- IEEE 1159 or EN50160 power quality analysis, statistics & reports
- Sags/swells/interruptions detection
- Pulsed transients detection (pulse width >150 ms)
- IEC 61000-4-7 harmonics & inter-harmonics
- Directional power harmonics
- IEC 61000-4-15 flicker
CONTROL & ALARM FUNCTIONS
- 32 programmable set points
- 5 slots for plug-in I/O modules
- Up to three modules of 16-channel digital inputs
- Up to four 8-channel relay output modules
- Up to four combined 4-channel analog input/output modules
- Up to two 8-channel fast (1 ms) analog input modules
COMMUNICATION
- Three independent serial communication ports
- Infrared port
- Built-in modem
- Ethernet
- USB port
- Protocols: Modbus RTU & ASCII, DNP 3.0, TCP/IP
- Optional IEC 61850 protocol
|
|
Wide range of panel, power analyzers (in different sizes and functions), allowing connection to a PC using RS-232 or RS-485 systems, according to type. Option to connect peripheral equipment to extend its functions, according to the type of analyzer. This may be internal memory, relays, digital and/or analogue outputs, etc. It has powerful SCADA software to manage and control electrical parameters and other analogue and digital parameters.
Power quality analyzers to detect disturbance in the electrical system (in panel or portable versions). According to the type of equipment, they can detect: slow voltage variations, rapid voltage variations, interruptions, dips, overvoltages, microcuts, etc., that are reasons for machine stoppages, resets in PLC, etc.
|
|
|
|
|
|
|
SIRIUS89N is a complete model to perform all safety tests in compliance to VDE 0413, measure of values of environmental parameters (temperature/humidity, illuminance, sound level with optional probes), leakage current with optional clamp and to perform a network power quality of single phase in compliance to EN50160 guideline.RCDs which suddenly trip out, transformers which overheat, motors which burn out, voltage sags and surges which create problems, all these problems could be easily solved with SIRIUS89N. The meter permits to perform a Loop impedance measurement (P-P, P-N, P-PE) also with high resolution (0.1mOhms) with the use of IMP57 optional accessory and five predefined recording settings are integrated in order to to help the user on the most common situation which are present on the network quality (EN50160, Voltage Anomalies, Harmonics, Start-Up and Power & Energy). SIRIUS89N can perform current measurements up to 3000A AC also by using a flexible clamp type in order to perform measurements on big cables or bars also. Thanks to the PC interface and the powerful software you will create accurate documents qualifying your professionalism more and more.
|
|
One of our most popular PNA (power network analyzers) is the DEWE-560-PNA. With 4 x voltage and 4 x current inputs, and packaged in a rugged high-impact enclosure, we have pushed the envelope tremendously in putting a powerful analyzer into an incredibly convenient and portable box!
Isolation? Of course. The DEWE-560-PNA meets and exceeds all of the international norms and specifications that you need and expect. In one incredible package we have put a powerful 3-phase analyzer capable of handling any base frequency - including variable base frequencies - up to 800 Hz!
|
|
The MC660 / MC666 network analyzer is used for permanent analysis of electricity supply quality in compliance with the SIST EN 50160 standard. Reports are stored in the internal memory for the period of the last 7 years.
Moreover, more than 170,000 deviations of the measurements from the standard values are stored, which enables finding eventual reasons for the problems in network. Optional limits and required quality in a monitored period can be defined for each monitored characteristic.
The following characteristics are measured and recorded:
- Frequency deviations
- Voltage deviations
- Voltage dips
- Voltage interruptions
- Voltage unbalances
- Over-voltages
- Fast voltage changes
- Flicker intensity
THD
Harmonics
|
|
* The price of a low cost instrument, the features and performance of a middle class instrument, the weight and form of portable instrument.
* Addresses the entire market for design, production, service and installation.
* Universal RF analysis. The most important instruments in one box;
o bidirectional 2-port vector network analyzer to characterize all 4 S-parameters,
o optional spectrum analyzer,
o optional power meter (with an R&S NRP power sensor)
* Fully portable; weighs less than 7 kg, optional battery power
* Frequency ranges from 9 kHz to 3 GHz / 6 GHz
|
|
| ... products without technical information |
| |
|
Agilent network analyzers accurately characterize components by measuring their effect on the amplitude and phase of swept-frequency and swept-power test signals.
|
|
|
|
|
|
NetSpector enables protocol analysis in switched networks from one central point. The network sniffer is modularly designed: Display unit and recording agent are separate and can be used at different locations.
The display unit is the user interface with which data recording is controlled and the recorded data are indicated. The recording agent is responsible for the actual recording (capturing). It is either installed on the same station on which the display unit was installed or – and this is the special feature – on a remote station.
The recording agent records network communication on the remote station and, when necessary, sends it to the indication station. The display unit can be run on the local workstation while the recording takes place remotely on a switch.
Real and local data flow can be recorded by targeted placement. The problematic effects of active components connected in between (routers, switches, bridges) are thus avoided.
NetSpector captures all frames from the start up. Each station participating in network communication is registered and added to a station list. From the station list you select the station to investigate and you create the frame list of the selected station. The colour labelling of the frames makes it easier for you to find individual frames. The frame you see fully decoded and in detail in the frame detail window. In addition it is also possible to display the frame content as hexadecimal and ASCII in the frame hex window.
|
|
| ... products without technical information |
| |
|
|
|
|
SPECTRAN® HF-2025E (700MHz to 2,5GHz)
- DECT & TimeSlot Analyser
- REALTIME PEAK power detector (option)
- USB 2.0 interface
- Direct RF spectrum display!
- High performance DSP (Digital Signal Processor)
- Frequency and signal strength display!
- High resolution multifunction display
- Exposure limit calculation according to DIN/VDE 0848!
- AM demodulation
- Advanced HOLD function
- Switchable PULS mode
- Incl. battery pack and charger
- Incl. HyperLOG 7025 EMC antenna
- Frequency range: 700MHz to 2,5GHz
- Typ. level range: -80dBm to 0dBm
- Typ. accuracy: +/- 4dB**
The SPECTRAN HF-2025E is our ultimate RF measurement device for the novice at an unbeatable price!
Several included accessories (LogPer antenna, special battery, charger and transportcase) and the extended functionality (like DECT analysis!) particularly allow the novice PROFESSIONAL measurements at an affordable price. Option power detector for REALTIME power measurements.
This NEW Revision3 offers a lower noise level and a optional REAL TIME power detector.
|
|
| ... products without technical information |
| |
|
|
