The performance seen from all angles with Stäubli 360° socket: Freedom, Performance and Safety.
Designed for maximum efficiency the revolution Stäubli is unique:
- User friendly
- Light
- Reliable
- Anti-hose whip safety device
Thanks to the 360° and 90° double swivel action, the new revolution Stäubli couplings follow your every movement.
Performance is greatly enhanced by incorporating the swivel directly in the socket thus creating:
- Excellent air-flow,
- Perfect leak-tightness,
- Very compact assembly.
|
|
NS4 Non-Spill Quick Disconnect Couplings
Colder Products’ patented NS4 Series couplings feature non-spill valves in a compact size, at a great price. Use the NS4 when even a few spilled or leaked drops of fluid pose problems regarding safety, environmental regulations or media cost. These innovative couplings are lightweight, chemically resistant and easy to use. The non-spill design virtually eliminates spills, minimizes downtime and enhances operator safety.
|
|
|
|
|
|
NS2 Couplings Deliver Cost-Efficient, High-Flow Fluid Line Transfer in a Small Footprint, Safely and Economically
Colder Products’ NS2 Series compact, non-spill quick disconnect couplings provides users with fast, safe and virtually leak-free fluid line connections. An excellent choice for printing and ink management, analytical instrumentation, electronic cooling, and many other applications, the patent-pending NS2 couplings provide high-flow fluid transfer in a small footprint.
For applications that require the safe transfer of fluids, the NS2 offers an easy, twist-to-connect locking mechanism and double-sided non-spill shutoff valves for added safety and convenience.
The NS2 meets the need for smaller, more cost-effective industrial couplings. The smaller couplings can replace larger ones, offering users a low-cost, space-saving option for a wide variety of coupling applications. The NS2 couplings also offer very low air inclusion – air induced into the coupling upon connection – minimizing contaminants and reducing the need to purge fluid lines.
Colder NS2 Series quick disconnect couplings are available in a variety of sizes and configurations.
|
|
NSH Series Couplings
Colder Products’ patented NSH Series couplings feature a pressure-balanced, non-spill design and a 100% metal-free, spring-free flow path at a very competitive price. These innovative couplings are easy to use (single-handed operation) and provide high flow capacity. Their non-spill design virtually eliminates spills, minimizes downtime and enhances operator safety.
|
|
Non spill design
Flush faced and non-spill, HCB ensures no air inclusion into the system when connecting as well as spillage when disconnecting.
Easy to use
Compact and user friendly, the HCB connector is easy to operate. In connected position, plug and socket dust caps can be mated together. Stainless steel dust caps available on request.
Applications
All fluids
* gas
* steam
* vacuum
* aggressive fluids
for all industrial sectors.
|
|
|
|
|
|
Standard and vented safety styles in numerous versions with 10 bar to 35 bar (145 PSI to 508 PSI) maximum working pressures, offering important benefits in compressed air applications:
Easy Handling
- Pre-applied thread sealant—Results in quick, easy air-tight installation
- Low connection force—Minimizes operator exertion, eliminates fatigue
- One-hand operation—Allows fast, secure connection and disconnection
High Efficiency
- High flow—Allows improved tool performance
- Extremely low pressure drop—Permits lower energy consumption
- Air-tight design—Prevents air loss during connection and operation
Long Life
- Hardened steel nipple bodies and locking sleeves—Offer maximum wearing strength, uninterrupted service
- Close tolerances—Ensure smooth, efficient operation
- Smooth machined parts—Ensure properly aligned mating parts for air tightness
- Pre-lubricated locking balls—Prevent premature wear, provide improved vibration resistance
- Chrome-, nickel, or zinc-plated exposed surfaces—Ensure corrosion resistance, protection in harsh environments
|
|
More flexible, clean and reliable coupling: the new range of quick action and safety couplings for all types of industrial applications.
• Wide range of variants with nominal sizes from 1.5 to 13 mm and flow rates from 40 to 2,000 l/min
• Particularly suitable for applications with fluid media - the new quick coupling KD…-R with double-sided shut-off function
• Maximum safety for man and machine thanks to patented release process of safety couplings KDS: rotating, pulling and releasing
|
|
Miniature push-in fitting for maximum component density in minimal installation space. For pneumatic applications with a temperature range up to 60° C (at 6 bar), and a pressure range up to 10 bar. Outside tubing diameters of 3, 4 and 6 mm with M3, M5, M7, R1/8 and G1/8 connecting thread.
Recommended tubing: PUN
|
|
|
Parker's industrial quick couplings represent the broadest range of quick couplings for most media. Dry-break and non-spill quick couplings contamination free for safety and protection of environment.
|
|
With STÄUBLI RCS COMPACT couplings, the exclusive STÄUBLI features of:
- safety,
- automatic push button locking,
- optimal flow,
- long term leakproof reliability,
are incorporated into limited space and weight.
|
|
|
The F-4150 series Quick Disconnect simplifies tubing connections during assembly. The 10-32 UNF male-threaded Quick Disconnect is available in three barb configurations: straight, elbow, and tee. Depress the latching pushbutton to remove the barb; re-insertion of the barb locks it into position. Barbs can be provided for 1/16”, 1/8”, or .170 I.D. tubing. The unique design allows the fitting to swivel 360 º.
|
|
Internal end of the Beswick miniature screw-type quick disconnect. The screw-type quick disconnect allows for fast set-up and break-down of fluid lines and facilitates easy component replacement. When the internal end (QDC-1F, QDC-2F or QDC-5F) and the external end (QDC-1M, QDC-2M or QDC-3M) are screwed together, a valve in the external end opens to permit flow. When the external end and internal end are disconnected, the valve in the external end closes to prevent fluid from exiting. The QDC-4F and QDC-5M can be used when no shut-off valve is needed. The screw-type quick disconnects are economical and a good choice when connects/disconnects are infrequent. Beswick snap-type quick disconnects may be a better choice for more frequent connects/disconnects or greater convenience is desired.
Material: Brass body & nut with one steel E-ring.
|
|
|
Global Manufacturer of Quick Release - Quick Disconnect - Quick Connect Hose Couplings in General Purpose Poppet and Dry Break - Non Spill (Flat/Flush Face) styles for virtually any Hydraulic or Pneumatic fluid application. Many styles available from ISO Interchange designs to subsea, panel mount, screw to connect, connect under pressure, and many specialty designs are available from Snap-tite.
|
|
|
|
|
|
Our experts for special cases: Highest safety ex works!
Ball-Face Clean Break coupling for difficult fluid or gaseous media
BF series
Features:
Clean break coupling made of stainless steel, especially suited for difficult fluid or gaseous media. Adhering to highest safety standards and optimally operable through automatic locking, they are primarily designed for applications in the chemical industry.
This series is suited for non-lubricating media (as e.g. demineralised water, “dry gases”) as well as lubricating media. Tried, tested and proven for solvents, chemical fluids and water vapour. Also used for lyes, a wide variety of acids and many other media.
Key Benefits:
• clean break (low-loss operation with few inclusions)
• easy to clean smooth ball-face outer surface
• squirt-free
• minimal couple force
• safety through positively controlled locking and valve opening process (nominal
sizes 25 and 50 mm)
• automatic locking
• well proven
• nominal sizes 25 and 50 mm connectable under operating pressure by separate locking and valve opening process
Nominal Sizes:
5, 9, 12, 25 and 50 mm
Media:
• water, water vapour, solvents, acids, soap solutions, lyes, oils, all non-lubricating media and many more
• for difficult and gaseous media, primarily for the chemical industry
Pressure range:
up to 64 bar, depending on the nominal size
|
|
Camozzi offers a large selection of fittings and accessories suitable for a wide range of applications. Universal fittings, super-rapid fittings, quick-release couplings and accessories are available in different dimensions from M5 to G1/2. Our fittings range includes the patented and longstanding “Sprint” system that guarantees tightening and facilitates the repeated removal and reassembly of the fitting.
|
|
All-purpose low pressure series LP / SP
Features:
The LP / SP series comprises single and double shut-off couplings in nominal sizes from 2.5 to 50 mm. This series is available in different materials with various surface coatings.
Key Benefits:
• universally applicable
• extremely hard-wearing & durable
• various seal materials
• variety of optional equipment, e.g. unlocking device, venting valves
• nominal sizes 4, 6, 7, 12 and 19 mm in a squirt-free version
• broad spectrum of connection types in the standard version
• locking aid
• ring grips optionally available for large nominal sizes
Nominal Sizes:
2.5, 3, 4, 6, 7, 9, 12, 19, 32 and 50 mm
Media:
• water
• compressed air
• diverse fluids
• fuel
• lubricating greases / oils
• technical gases
Pressure Range:
up to 100 bar (some types up to 200 bar) depending on nominal size and material, partially suitable for vacuum
|
|
|
|
|
|
Multiline - (4 / 6 / 8 Line) - QDC
Description: The snap-type multiple line quick disconnect features a releasing sleeve that permits one-hand connecting or disconnecting of several fluid lines simultaneously. Simply push the sleeve in to disconnect the fluid lines and push the internal and external ends together to connect the lines. The design incorporates a keyed location pin to insure correct orientation of the fluid lines during connection. The internal end is designed with an automatic shut-off valve.
Material: Internal: brass or 303 stainless steel components; acetal releasing sleeve; stainless steel mounting plate, springs, ball bearings, set screw, crescent “C” rings and steel “E” ring. External: 303 stainless steel components; stainless steel backing plate
Seals: Internal: three Buna-N O-rings, OR-QDC-B (3 O-rings), for each line. Optional materials: EPDM, Viton®, Silicone, Chemraz® and Fluorosilicone.
Note: Multiple line quick disconnect can also be ordered in 316 stainless steel and double shut-off configurations. Contact factory for ordering information.
|
|
The range of "Quickconnect couplings" makes easier and quicker connection and disconnection of movable tubes from compressed air systems without stopping the flow upstream.
The new "Safety Quick Couplings" (600 serie) use a very sharp internal structure that release air downstream before plug can be removed. Safe disconnection is assured with no whiplash. To connect just push the plug into the socket. To disconnect just push the sleeve backward. Plug can be removed safely when air has fully exhausted.
The various models distinguish theirselves with a different standard, which ideally match the most common international couplings.
Fittings are available in the following sizes:
tube from 4 up to 19;
thread of 1/8 to 1/2
Fluids: Compressed air
Connection tubes: Flexible tubes in plastic and rubber.
Temperatures:
Minimum: -18 °C
Maximum: +80 °C
|
|
Safety through non-interchangeable closings
UF series
Features:
The HP series comprises single and double shut-off couplings in nominal sizes from 6 to 32 mm.
Thanks to different shapes (triangular, square-cut) of coupling and adaptor, only coupling halves with the same closing can be connected. A round design is also available in the scope of supply of the LP series.
Key Benefits:
• non-interchangeability
• various seal materials
• broad spectrum of connection types in the standard version
• unlocking device
• ring grips optionally available for large nominal sizes
Nominal Sizes:
6, 7, 12, 19 and 32 mm
Media:
water, compressed air, diverse fluids, fuel, lubricating greases / oils, technical gases and many more
Pressure Range:
up to 40 bar (depending on nominal size and material)
|
|
Coupling products that promote the use of compressed air in a safe manner. Specially designed to protect individuals from harm by guarding against workplace injuries, the products include:
- Vented safety couplings with recoil dampening—Disconnect in two stages, in order to vent the coupling, minimize risk of component separation, reduce noise, and prevent recoil accidents; available in five popular series up to 232 PSI (16 bar)
- Couplings with added locking feature—Require operator to deliberately disengage the nipple from the coupling, preventing unintentional disconnection
- Anti-hose whip nipples with recoil dampening—Include a non-return valve that vents downstream pressure when disconnected and reduces noise; secure hose ends to prevent whipping of hose that may occur upon disconnection
|
|
Series LS
Nominal bore:
6, 9 and 11 mm
Working pressure:
up to12 bar
Media:
compressed air
Materials:
coupling housing: steel durnicoated
locking sleeve: brass passivated
Special features :
Compressed air safety coupling with automatic lock and very high flow rates; a special design avoids the dangerous whip effect completely.
The safety coupling is "DEKRA type-tested".
Fits onto different nipple contours.
see also Series LS in large nominal sizes(12, 23 and 38 mm)
|
|
All-purpose medium pressure series MD
Features:
The series MD comprises double shut-off couplings in nominal sizes from 6 to 50 mm. This series is available in different materials with various surface coatings.
Key Benefits:
• unlocking device
• universally applicable
• extremely hard-wearing & durable
• various seal materials
• variety of optional equipment
• broad spectrum of connection types in the standard version
• ring grips optionally available for large nominal sizes
Nominal sizes:
6, 7, 12, 19, 25, 32 and 50 mm
Media:
• water
• compressed air
• diverse fluids
• fuel
• lubricating greases
• hydraulic oils and many more
Pressure Range:
up to 250 bar (depending on nominal size and material), partially suitable for vacuum
|
|
|
SafeWay’s FFE49 Series is a non-spill, push-to-connect, fluid transfer quick coupling designed for use with most industrial fluids. This series is interchangeable with quick couplings meeting International Standard ISO 16028 dimensional requirements, and our field proven, heavy-duty FF49 Series. Some basic applications include skid-steer loaders, power utility equipment, construction equipment, agricultural equipment, and hydraulic hand tools. Use this quick coupling series whenever spillage can result in a safety or environmental hazard, when air inclusion during connection to a hydraulic system cannot be tolerated, and when international interchangeability with other brands is required.
|
|
99 KL series
With the 99 KL series, both the coupling as well as the plug are filled with a dry-break valve system. During the connection process, the plug and the coupling seals before both valves open. The valves close simultaneously when disconnected, allowing the coupling and plug to be seperated afterward. This ensures minimum leakage. It cannot be connected with any other design in this series. All invidual parts are electro-burnished.
Advantages
Coded via two lateral grooves on the plug and a similar guide in the coupling, which are arranged in different angular degrees. The 8-way coding is standard.
Applications
Mechanical engineerring, plant machinery, chemistry
|
|
180 and 280 Miniature Pneumatic Couplings
The 180 Miniature Ball Lock Quick-Connect One-Way Coupling is designed for use with compressed air, gases and liquids. The manually operated devise features a ball lock and mates with all Series 180 plugs. Series 180 features a tire valve and has the option of viton seals. Series 280 features a 1-HK valve, which provides higher flow capacity and also has the option of viton seals.
Features:
- Ball Lock
- Manual operation
- Series 180 and 280 sockets mate with all series 180 plugs
- Series 180 socket has a tire valve. Series 280 socket has 1-HK valve, which provides higher flow capacity
- Viton seals available as an option. add - 143 suffix to socket par number when ordering.
Standard Materials:
°Socket
- Brass Body and sleeve
- Valve
* 180: Nickel plated brass tire valve
* 280: Brass series 1-HK valve
- Buna-N (Nitrile) seals
- Stainless steel springs
- Stainless steel locking balls
°Plug
- Brass Body and sleeve
- Brass
|
|
|
We offer a range of specially designed 4mm fittings for miniature pneumatics applications. The range is both compact and robust. Ends with M3 and M5 threads are designed to only need finger tightening.
|
|
Push to connect fittings in brass nickel plated
The MA is our "Automatic push-in fitting" line. It enables quick connections with calibrated plastic hoses at any time, at any stage of the pneumatic circuit and by simple hand movement.
The connection and the fitting tightness are made possible by the presence of the stainless steel grip and of an Oring inside the fitting so that once the tube is inserted to the bottom of the fitting, the stainless collet grips onto it and prevents it from being released. The tube disconnection is then possible by pushing onto the outer metal ring, called release ring.
All MA fittings are brass nickel-plated
|
|
|
|
|
|
48 KB series
The 48 series coupling system made of POM and PVDF has been developed for use in the medical, chemical, food handling, pharmaceutical and laboratory technology industries. The coupling is also available in a completely thermoplastic version (RectuChem ). Here the metal springs are replaced by springs made of PEEK, an extremely resistant synthetic material.
Advantages
The coupling is fitted with a double shut-off valve which enables it to be connected to a single shut-off (non-valved) plug as well as a double shut-off (i.e. plug with valve). The coupling is also available as a straight through coupling (valved plug).
Application
Medical engineering, dental equipment, measuring and control equipment, laboratory, pharmaceutical.
Working Pressure : PB = 0 - 10 bar (POM, bei 20°C), PB = 0 - 8 bar (PVDF, springs made of steel), PB = 1 - 8 bar (PVDF, springs made of PEEK), maximum static working pressure with safety factor of 4 to 1.
Working Temperature: -20°C up to 80°C (POM), -20°C up to 120 (PVDF), depending on the medium.
|
|
Specifications
Material: Steel
Temperature Range: -40 to 121°C (-40 to +250 °F)
Coupler Size:1/4 Inch (6.3 MM)
Overall Length (A):1.62 inches
Description: Tip Half
Thread: 1/4 Male Pipe
Body Size:1/4 inches
Maximum Operating Pressure: 20 BAR(300 PSI)
Series: S80
Wrench Hex (C): 0.56 inches
|
|
Industrial customers are always interested in technological solutions helping reduction of idle times during set up operations on machining centers, tooling machines, test benches and other devices.
For these particular applications, Faster presents a complete range of specific products purposely designed for INDUSTRIAL connection needs.
Applications
Connection of:
- hydraulic components for automation systems
- components in chemical plants
- components in charge plants for technical gases
- components in off-shore plants
- components in food industry plants
- components for hydraulic final testing
- components for robotized painting systems
- components for hydraulic test benches
- temperature control systems for plastic and metal casting
- hydraulic components for industrial applications
- hydraulic systems in steel industry plants
- hydraulic systems on machine tools
|
|
|
|
