* Easily programmed
* Weld parameter monitoring
* Automatic self-compensation
* PC data interchange
* 63 weld schedules per outlet
* Closed loop control and feedback
* Alert and fault output displays
* Self diagnostics
* Robotic, fixed automation and manual systems available
|
|
Designed specifically for the insulation industry
The Pin Welders robust and reliable design has performed efficiently and reliably for many years under the stress of on-site and workshop conditions.
The unique chuck guard design has the following advantages:
1. No adjustment necessary for different length pins.
2. Protects chuck from zinc splashing during welding, therefore increasing the life of the chuck.
3. Because of the self-tightening effect between the chuck and the chuck guard, arcing between the chuck and the pin is eliminated therefore guaranteeing more consistent welding results
|
|
|
FEATURES: Plug in solid state circuitry. Continuous current control from 250 to 900 amps. Continuous time control from .05 to .7 seconds. Built in chuck saver. System comes complete with 8 meters earth cable and clamp, 15 meters weld and control cable and stud welding gun with legs and foot piece.
|
|
JUPITER 300i
Site generator with regulated and adjustable welding current, version inverter.
Welding of insulation attachment stud &0slash; 3 standard, mild steel, stainless steel, aluminium and bi metal.
|
|
Designed specifically for the insulation industry
The Pin Welders robust and reliable design has performed efficiently and reliably for many years under the stress of on-site and workshop conditions.
The unique chuck guard design has the following advantages:
1. No adjustment necessary for different length pins.
2. Protects chuck from zinc splashing during welding, therefore increasing the life of the chuck.
3. Because of the self-tightening effect between the chuck and the chuck guard, arcing between the chuck and the pin is eliminated therefore guaranteeing more consistent welding results.
|
|
The SGC 66 Percussion is a new generator which can weld is in
contact mode is in percussion mode.
It is the most compact generator and lightest in its category.
Managed by Microprocessor, it is equipped with a meter
of recording (counting of the number of weldings and time counting).
It is the ideal tool for all the weldings on stainless steel,
aluminum, brass, coppered mild steel, in the diameters m2 in M8, and
it finds its place in very many applications:
aeronautics, fine sheet-iron works, electric household appliances, articles domestic,
automotive engineering, cycles.
|
|
| ... products without technical information |
| |
|
Starting from basic standard elements (generating, heads of welding, management systems, slot-machines...), C2G realizes on automatic equipment, schedule of conditions to weld very high efficiencies and technicality being integrated completely into the manufacturing processes, to meet all the requirements in welding such SIG (Stud Inert Gaz), ARC (ARC fusion forging) or DEC (Discharge of condensers).
|
|
| ... products without technical information |
| |
The weld lugs are available in numerous dimensions and types in order to meet all your specific welding solutions.
Quick and easy to fit, AMECA weld lugs offer high resistance to pulling without deforming the substrate sheet metal.
They are quickly fitted and enter perfectly into the quick welding processes required today by the metallurgy industry.
|
|
|
KCD manufactures a huge range of metric and BSW studs. We can design and make almost any size, shape or configuration - threaded or non-threaded, in mild steel, stainless steel or aluminum. Standard popular studs are held in stock, ensuring 24 hours delivery
|
|
The pins to weld C2G are available in many dimensions (m3 in M25) and types in order to answer all your solutions of specific welding: SIG (Stud Inert Gas) - ARC (ARC fusion forging) or DEC (Discharge of condensers).
The quality of the pins to weld C2G confers a very great tear strength to them while allowing a fast and easy installation in the processes of fast welding imposed today by the metallurgy.
|
|
| ... products without technical information |
| |
Welding head ta1040
Can be supplied by an automatic distributor, or be used semi-automatically or manually with the 3 standard processes.
|
|
G20C Welding gun
Welding gun working with the DischargE Condenser Process Contact mode, fitting on all SGC generators for Ø 2 to 8 mm studs.
|
|
| ... products without technical information |
| |
|
|
