ozone resistance test chamber / aging / stainless steel / automatic
HD-E801-A HAIDA EQUIPMENT CO., LTD

{{requestButtons}}

Characteristics

  • Type:

    ozone resistance, aging

  • Options and accessories:

    stainless steel, automatic

Description

Ozone aging test chamber is a major factor in rubber cracking although it is rare in the atmosphere, ozone aging tank simulates and enhance the condition of ozone in the atmosphere to study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging measures to enhance the life of rubber products.

Technical parameter:
1.studio size: 500 × 600 × 500 150L
2 .ozone concentration 0 ~ 1000pphm, PID settings.
3 .ozone concentration deviation of 5%
4 .Test sump temperature: RT ~ 85 ℃ (Recommended temperature 40 ℃)
5 .Test Position Humidity: 20 ~ 85 ℃ (recommended humidity 65%)
6 .Temperature uniformity: ± 2 ℃
7 . rack rotation speed: 2R/min adjustable
8 . sample pulled Frequency: 0.5Hz
9 . Supply voltage: 220V ± 10%


Corresponding standard:
JIS K 6259 , ASTM1149 , ASTM1171, ISO1431, DIN53509 , GB/T13642, GB/T 7762-2003
GB 2951
