Couplings

Torque: 100 Nm - 3,240 Nm

STANDARD FLEXIBLE COUPLINGS FOR MANY AREAS OF APPLICATION “Standard” flexible couplings are elastic coupling elements developed for installation in the most diverse drive train applications. ...

Torque: 210 Nm - 6,480 Nm
Rotational speed: 0 rpm - 12,000 rpm

... FLEXIBLE COUPLING ASSEMBLY The new SGFlex-3F Series coupling system incorporates industry proven SGFlex couplings with solid steel flanges or flywheel combinations to provide an integrated ...

Torque: 3,900 Nm - 44,200 Nm
Rotational speed: 3,400 rpm - 4,100 rpm

The new SGFlex-LC coupling system covers the torque range between our SGFlex-3F and TENBEX-ECO coupling systems. The SGFlex link assemblies inside the coupling work with seperate link ...

Design: Housing made from stainless steel , seals made from FKM. Application: For connecting two components at a short distance without using fittings. They are designed for pipeline and screwless pressure oil connection. Note: The ...

Torque: 46 Nm - 17,000 Nm

ETP-EXPRESS is a hydraulic connection which has only ONE screw for pressurising. It is especially suitable for repositioning of the hub fast and accurately. The screw is tightened in the radial direction, this means no space is used ...

Torque: 60 Nm - 1,600 Nm

ETP-POWER is a hydraulic connection with the highest performance among the single screw ETP hub-shaft connections. With ETP-POWER all the positive benefits and features of hydraulic clamping, such as easy handling, compact design and ...

Torque: 50 Nm - 32,000 Nm

ETP-TECHNO is a hydraulic connection with very high precision. It is especially designed for applications where fast frequent changes or adjustments, with high precision are needed. It can be mounted/dismantled 1000´s of times ETP-TECHNO ...

Torque: 100 Nm - 150,000 Nm

Universal Joint Shaft Couplings Fits standard DIN UJ (Universal Joint) companion flanges. Release torque is adjustable by Wedgepin ratings. The maximum release torque is based on maximum Wedgepin ...

Torque: 2,030 Nm - 26,155 Nm

Universal Joint Shaft Couplings Quick manual shearpin reset with Wedgegard® system Fits standard SAE UJ (Universal Joint) companion flanges. Release torque is adjustable by Wedgepin ratings. The ...

Torque: 2,785, 761,403, 3,230, 8,024, 21,557 Nm

Chain Type Wedgegard Couplings are supplied bored and keywayed to customer requirements.. Standard Units for release torques up to 64,000 Nm. Torque is adjustable by Wedgepin ratings. Designs to suit special drive requirements ...

Torque: 190 Nm - 2,800 Nm

Cone Clamping Elements RLK 110 K centres the hub to the shaft corrosion protected Features - Centres the shaft to the hub - All parts 35 µm chemically nickel-coated for high corrosion resistance pursuant to DIN 50021 (neutral salt ...

Torque: 840 Nm - 414,500 Nm

Cone Clamping Elements RLK 402 TC centres the hub to the shaft Premium quality with double slot Features - Centres the hub to the shaft - Highest transmissible torque - For heavy duty applications - No axial displacement between ...

Torque: 7,000 Nm - 1,206,000 Nm

Cone Clamping Elements RLK 404 centres the hub to the shaft high transmissible torque Features - Centres the hub to the shaft - High transmissible torque - No axial displacement between hub and shaft during clamping procedure - ...

Set collars with universal applicability, e.g. as a fixed stop. Set collars with strong clamping force. Material Screw steel stainless steel Set collar Steel, black, steam oxidized Stainless steel 1.4404

Clamping rings are provided with a fastening possibility for sensors, switches etc. Universal applicability, e.g. as a limit switch on a piston rod. Clamping ring made of stainless steel with strong clamping force. Material Screw ...

Quick plug coupling with radial offset compensation for multiple applications, e.g. as a link between a piston rod and a linear movement unit. Material Claw Heat-treated steel, tempered, phosphated Coupling ...

Torque: 0.0565 Nm - 282.4621 Nm

Magnetic couplings offer a non-contact transfer of torque. They are typically used in magnetic drive pumps and magnetic mixers for seal-less applications; keeping corrosive, toxic, or flammable liquids from escaping into ...

Torque: 0.1129 Nm - 53.1 Nm

Disc type magnetic couplings consist of two opposing discs with powerful rare earth magnets. The torque applied to one disc is transferred through an air gap to the other disc. Because of its simple flat design, you can ...

... shaft is not serrated, as this would add little torque to the coupling and the increasingly narrow teeth would not be practical for cutting. The coupling of the Toothed Discs – Hirth Coupling ...

Torque: 3.6 Nm - 2,380 Nm
Rotational speed: 2,100 rpm - 10,000 rpm

The Nil-Union elastic coupling model 1 is very suitable at the entrance and exit of gearboxes, for machines or heavy-duty devices and also for machines with frequent stops and starts under full load or with alignment ...

Torque: 1.5 Nm - 237 Nm
Rotational speed: 3,500 rpm - 12,000 rpm

The Nil-Union elastic coupling models O and L differ in the length of the crown. The L model has the longest crown, and is especially suitable for use between any receiving machine and an electric motor with alignment ...

Torque: 380 Nm

Couplings G-GM Series: G series: max 1250 Nm GM series: max 380 Nm

... Two types are available: solid-hub couplings, designed to be remanufactured to customer specifications -Couplings associated with removable hubs making installation very easy. Conditions of use ...

Torque: 10 Nm - 975 Nm

These elastomer star couplings are used on servo shafts to overcome critical vibrations and when all-steel couplings reach their limits. They transmit torque without backlash and compensate for misalignment. ACPG ...

Torque: 11.5 Nm - 420 Nm

Curved-tooth couplings function as flexible connections. They are particularly suitable for transmitting high torques. They compensate for axial, radial and angular misalignments of the shafts to be connected. Gear couplings ...

Torque: 1 Nm - 25,000 Nm

... high-performance standard magnetic coupling series between 1-1,200 Nm, as well as customer-specific solutions from 0.1 -25,000 Nm. With various magnetic configurations, we can respond in detail to all customer requirements. ...

Torque: 1 Nm - 1,500 Nm

... combination with all common pumps and drive motors. A conversion kit converts a pump with mechanical seal and standard spider coupling, for example in a PU machine, into a hermetically sealed system. The conversion ...

Torque: 0.3 Nm - 150 Nm

... drives are available as overhead drive or bottom mounted drive. An agitator drive equipped with DST permanent magnetic coupling hermetically seals the agitator, thus preventing any escape of hazardous gases or the ...

Torque: 1.1 Nm - 65 Nm
Rotational speed: 9,000 rad.min-1 - 42,000 rad.min-1

... equipment / Mount machines / Medical / Machine tools / Packaging machines ● Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service -Cleanroom ...

Torque: 1.1 Nm - 35 Nm

... Actuator / Surface-mount machine / High precision XY stage / Index table Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service Please ...

Torque: 0.6 Nm - 200 Nm
Rotational speed: 6,000 rpm - 42,000 rpm

... for 1/10 taper shaft & clamping type) XHS-C (short, clamping type) Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service Application Actuator ...

Torque: 1 Nm - 15 Nm

• low-cost version with set screws • plug in - radial shaft displacement up to 3 mm • Torque range: 1 - 15 Nm • Shaft diameter: 3 - 19 mm • Temperature range -20 to +100°C

Torque: 1 Nm - 15 Nm

• standard series with radial clamping hub • plug in - radial shaft displacement up to 3 mm • Torque range: 1 - 15 Nm • Shaft diameter: 3 - 19 mm • Temperature range -20 to +100°C

Torque: 0.7 Nm - 12.5 Nm

• low-cost version with set-screw • plug in - oscillation dampening • Torque range: 0,7 - 12,5 Nm • Shaft diameter: 3 - 14 mm • Temperature range -20 to +70°C

• Under initial tension no backlash shaft connection • Triple axially pluggable version • Simple blind mounting, no time-consuming screwings • Small structural dimensions – low flywheel effects • Maintenance free, simple optical ...

SOFTEX® FA COUPLINGS The torsionally flexible Softex® couplings are maintenance-free and have good dynamic properties. The drive couplings are also available as Softex® FA flange couplings, ...

... applications in the mechanical engineering • Friction-locked, detachable shafts / hub connections • Coupling combination TL 1/1; TL 2/2 and TL 1/2 possible • Coupling hubs TL 2 axially separable • ...

Torque: 0 Nm - 21,000 Nm
Rotational speed: 600 rpm - 4,000 rpm

HYDRAULIC COUPLING FOR ELECTRIC ENGINES – STARTER The TRANSFLUID coupling (K series) is a constant filling type comprising of three main elements: Driving impeller (pump) mounted on the input ...

Rotational speed: 0 rpm - 4,500 rpm

HYDRAULIC COUPLING FOR DIESEL ENGINES – STARTER The KFBD series Constant Fluid Couplings are used on all industrial equipment driven by internal combustion engines up to 500 kW. By transmitting power ...

Rotational speed: 1,000 rpm - 1,800 rpm

... driven machine. The coupling can work using both oil and treated water as standard. KX SERIES HYDRAULIC COUPLING: OPERATING CONDITIONS The fluid quantity in the working circuit is less than in traditional ...

Torque: 0.05 Nm - 10 Nm
Rotational speed: 0 rpm - 15,000 rpm

Miniature Metal Bellows Coupling with set screws  • Backlash-free miniature metal bellows coupling with radial set screws  • For shaft diameters from 1 – 24 mm  • High torsional stiffness, ...

Torque: 0.1 Nm - 10 Nm
Rotational speed: 0 rpm - 15,000 rpm

... Perfect bellows coupling for encoders, tachometers, potentiometers, servo drives, NC axis, stepper motors  • Torque range: 0,1 – 10Nm Miniature Metal Bellows Coupling with split hubs  • Backlash-free ...

Torque: 18 Nm - 1,400 Nm

Metal Bellows Coupling with collet clamps  • Backlash-free metal bellows coupling with clamp hubs  • Hub material: up to 60Nm – aluminum, up from 80Nm - steel  • For shaft diameters from ...
