Belt shot blasting machine MK series

for surface cleaningfor marblecontinuous

Product description
Marble shot blasting machines are designed for surface cleaning and finishing of stone products such as marble, basalt, granite, slabs, curbstones and cobbles. Workpieces travel on a conveyor while turbines mounted on the machine frame, set at suitable angles, project abrasive media to clean top and bottom faces. The continuous conveyor system enables in-line processing of semi-finished and finished parts with high throughput. Conveyor speed is adjustable per load via digital speed control to match part type and required blasting intensity.

Additional information
Machines are engineered and manufactured according to part dimensions, weights and daily production volumes. An optional dryer can be integrated to remove surface moisture before blasting when required. These machines are also marketed as marble sandblasting machines.

Models (summary table)
Model: MK 70 | MK 100 | MK 120 | MK 150
Blasting width (mm): 700 | 1000 | 1200 | 1500
Blasting height (mm): 200 | 300 | 400 | 500

Technical features / specifications

• Application: Surface cleaning / shot blasting for marble, basalt, granite, slabs, curbstones, cobbles, etc.
• Working principle: Parts advance on a conveyor; turbines angled to blast both top and bottom surfaces.
• System type: Continuous conveyor-based shot blasting system suitable for semi-finished and in-line parts.
• Conveyor: Adjustable speed with digital speed control to adapt to different part types and blasting requirements.
• Customization: Machines are designed and manufactured according to part size, weight and daily production output.
• Optional equipment: Dryer unit available to dry wet parts prior to blasting.
• Alternative name: Marble sandblasting machines.
• Available models and key dimensions:

  • MK 70 — Width: 700 mm; Height: 200 mm
  • MK 100 — Width: 1000 mm; Height: 300 mm
  • MK 120 — Width: 1200 mm; Height: 400 mm
  • MK 150 — Width: 1500 mm; Height: 500 mm
