AC/DC power supply iMP1 Series

switchingwith overload protectionexternal

The iMP1 series is an AC input to DC output configurable power system consisting of a microprocessor-controlled PFC front end providing seven slots that accept intelligent DC-DC converter modules with single, dual or triple outputs ranging from 2 V to 60 V. Single output modules come in four power ranges that can be mixed and matched and connected in parallel or series to obtain thousands of output combinations customized to any application. User-configurable functions include current limit and output sequencing, as well as input and output OK signals and indicators. Capable of delivering up to 1,500 W and with up to 21 isolated outputs, the iMP1 series carries full medical safety approvals and is an extremely flexible and versatile multi-output power solution. These digitally controlled power supplies feature a PMBus®-compliant I2C serial interface that enables parameters such as the voltage, current limit and enable/inhibit status of individual outputs to be programmed via an intuitive user GUI. The serial interface also allows remote monitoring of voltage, current and temperature. • ACOK signal • Active PFC • Configurable Output Sequencing • Digital monitor of Voltage, Current and Temp (Both Input and Output) • Downloadable GUI • EMI Conducted and Radiated to Class B • External Switching Frequency Sync Input • Field Replacable Intelligent Fan • Full Medical Approval • Global DCOK and Inhibit/Enable (Logic Programmable) • Margin and Remote Voltage Programming • Module DCOK and Inhibit (Logic Programmable) • Optional Conformal Coating
