Muffle oven RFD series

ashingagingelectric resistance

Product Overview
The furnace chamber uses 1200-type imported polycrystalline alumina fiber and a temperature-resistant ceramic inner box. An intelligent dual-shell cooling system activates the cooling fan automatically when the surface temperature reaches 50ºC. Constant-current soft-start control is applied to extend the life of the heating elements.

Description
The RFD series 1200ºC muffle furnace is designed for laboratory and industrial high-temperature applications such as aging tests and ash content determination for polymers, polyethylene, polyester, nylon, cork and similar materials.

Features

• Insulation: 1200-type polycrystalline alumina fiber and ceramic inner box.
• Control: Microcomputer PID + SSR + Timer for accurate temperature management.
• Cooling: Intelligent dual-shell cooling with automatic fan start at 50ºC surface temperature.
• Ventilation: Rear-wall vents, compatible with external fan or catalytic devices.
• Safety: Grounding leakage circuit breaker included.
• Power supply: AC 220V.

Technical Parameters
Model: RFD-15, RFD-20, RFD-30, RFD-40
Internal Dimension WxHxD (mm): 150×150×150; 200×200×200; 300×300×300; 400×400×400
External Dimension WxHxD (mm): 450×700×500; 500×750×500; 650×900×600; 650×900×700
Material: Inner box — temperature-resistant ceramic plate; Outer shell — 1.2t steel plate with powder coating
Temperature Range: RT+60°C ~ 1200°C
Accuracy: ±3.0°C
Control Method: Microcomputer PID + SSR + Timer
Power: AC 220V

Warranty and Service
One year free warranty for the complete unit; lifelong maintenance service. After-sales support includes response within 2 hours.

Package
Packed first with PP film, then 10 mm foam between machine and case, finally placed in a standard export plywood case.

Technical specifications

• Series / Model: RFD series (RFD-15, RFD-20, RFD-30, RFD-40).
• Chamber insulation: 1200-type imported polycrystalline alumina fiber.
• Cooling system: Intelligent dual-shell cooling; automatic fan start at 50ºC surface temperature.
• Heating control: Constant-current soft-start to extend heating element life.
• Control system: Microcomputer PID controller with SSR and timer.
• Temperature range: RT+60°C to 1200°C.
• Temperature accuracy: ±3.0°C.
• Construction materials: Temperature-resistant ceramic inner box; 1.2t steel outer shell with powder coating.
• Safety: Grounding leakage circuit breaker included.
• Venting: Rear-wall vents; compatible with external fan or catalytic device.
• Power supply: AC 220V.
• Warranty: 1 year free warranty; lifelong maintenance.
• Packaging: PP film, 10 mm foam, standard export plywood case.
