Climate chamber UV880

thermostatictemperaturehumidity

Product Description
This Xenon Arc Lamp Accelerated Weathering Test Chamber UV880 (ASLi XL-1000) reproduces the full solar spectrum to simulate sunlight, rainfall/condensation, temperature and humidity cycles for accelerated ageing and colourfastness evaluation. It is intended for R&D and quality control of materials exposed to outdoor conditions.

Introduction

• Designed to expose samples to controlled illumination, rain/condensation, temperature and humidity variations.
• Primarily used for non-ferrous metals, organic materials, rubber, plastics, coatings and construction materials to generate reliable aging data for product development and QC.

Product Parameters

• Model: XL-1000 (within UV880 series)
• Internal dimension (WxHxD): 1000 × 1000 × 1000 mm
• External dimension (WxHxD): 1550 × 2150 × 1550 mm
• Tube life: 1500 h
• Tube power: 1 kW or 6 kW options
• Illumination intensity: 340 nm: 0.35–0.6 W/m²; Full spectrum: 1200 ± 200 W/m²
• Filters: Quartz inner and outer filters
• Cooling: Water-cooled or air-cooled
• Power supply: AC 380 V (±10%), 50/60 Hz

Application
The UV880 accelerates climatic aging and colour-fading tests by simulating solar spectrum, irradiance, temperature, rainfall/condensation and humidity. Typical sectors: dyeing and finishing, printing, leather, plastics, acrylic, coatings, textiles, inks and rubber where lightfastness and weather resistance must be assessed.

Xenon Arc Lamp Accelerated Chamber Features

• ASLi-branded xenon lamp system reproducing ultraviolet, visible and infrared components of sunlight.
• Mature design and production under a controlled quality system.
• Realistic full-spectrum simulation for accurate colorfastness and weathering tests.
• Suitable for textile sun and color fastness testing across required spectral ranges.
• Enables assessment of color fastness, sunlight-induced aging and general weather resistance.

Technical Specifications

• Brand: ASLi
• Model: XL-1000 (UV880 series)
• Internal dimension: 1000 × 1000 × 1000 mm
• External dimension: 1550 × 2150 × 1550 mm
• Tube life: 1500 h
• Tube power options: 1 kW / 6 kW
• Illumination intensity: 340 nm: 0.35–0.6 W/m²; Full spectrum: 1200 ± 200 W/m²
• Filters: Quartz inner and outer filters
• Temperature control (BPT): 40–120°C (±3°C); (BST): 38–120°C (±3°C)
• Humidity range: Lighting 20%–75% R.H. (±5%); Dark 60%–95% R.H. (±5%)
• Sample holder rotation speed: 1–5 RPM adjustable
• Sample shelf diameter: 500 ± 50 mm
• Sunlight exposure cycle: 0.01 to 999 h 59 min
• Raining: period 1–240 min adjustable; duration 1–9999 min adjustable; spray pressure 70–130 kPa
• Spray flow: 1–2.4 L/min
• Exposure area: 7500 cm²
• Power supply: AC 380 V (±10%), 50/60 Hz
