Forward travel vibratory plate APF 15/40

gasoline enginecompacting

Overview The APF 15/40 is a forward-moving vibratory plate designed for versatile light compaction tasks on paving and asphalt. Optional accessories include a toolless Vulcolan rubber mat for paving-stone work and a water sprinkler system for asphalt. A generously sized, maintenance-free exciter unit provides strong forward movement, high travel speed and good climbing ability.

Key data

• Type: Forward-moving vibratory plate
• Model: APF 15/40
• Operating weight (depending on engine): 80–84 kg
• Working width: 400 mm
• Max vibration frequency: 100 Hz
• Max centrifugal force: 15 kN

Standard

• Petrol engine variants: Honda GX 160 (3.6 kW), Vanguard (3.7 kW), Rato (3.8 kW)
• Low-vibration guide handle
• Ammann colour scheme
• Weight examples: Honda 80 kg; Vanguard/Rato 84 kg

Options

• Vulcolan rubber mat (toolless installation) for paving stones
• Transport wheels
• Water sprinkler system for asphalt
• Hour meter

Engine specifications (table)
Manufacturer | Engine model | Fuel | Power output (ISO) | Nominal speed
Honda | GX 160 | Petrol | 3.6 kW | 3600 rpm
Rato | R180 | Petrol | 3.8 kW | 3600 rpm
Vanguard | 160 | Petrol | 3.7 kW | 3600 rpm

Applications & advantages Broad application range: the toolless Vulcolan mat adapts the plate quickly for paving-stone jobs; the water sprinkler system enables asphalt compaction. Compact dimensions, toolless daily maintenance and available engine variants provide flexibility for small to medium site tasks.

Technical specifications

• Model: APF 15/40
• Brand: Ammann
• Type: Forward-moving vibratory plate
• Operating weight: ~80 kg (Honda); ~84 kg (Vanguard/Rato)
• Working width: 400 mm
• Max vibration frequency: 100 Hz
• Max centrifugal force: 15 kN
• Power output (ISO): 3.6–3.8 kW (depending on engine)
• Nominal engine speed: 3600 rpm
• Standard low-vibration handle
• Options: Vulcolan mat, transport wheels, water sprinkler system, hour meter
