TFT-LCD monitor AMG-10IPHJ01T1

multitouch screenresistive touch screenLED backlight

Overview
The 10.4-inch industrial waterproof LCD monitor AMG-10IPHJ01T1 (Amongo) is built for harsh and outdoor environments where IP65 protection and continuous operation are required.

• Branded LCD panel with wide viewing angles and accurate image reproduction; industrial-grade components for reliable 24/7 operation
• Durable mechanical enclosure designed for demanding environmental conditions
• PCAP 10-point touchscreen option; optical bonding; anti-glare glass
• IP65 waterproof rating; high brightness with ambient light sensor for automatic dimming
• Customization and integration services available

Specifications
Model Name: AMG-10IPHJ01T1
Screen Size: 10.4"
Active Display Area (mm): 211.2(H) x 158.4(V)
Pixel Pitch (mm): 0.264(H) x 0.264(V)
Display Mode: Normally white
Display Color: 16.2M / 262K
Display Resolution (pixel): 800 x 600
Contrast Ratio: 500:1
Brightness: 1000 nits (with light sensor)
Backlight: LED
Viewing Angles (CR=10): 160° (H); 130° (V)
Response Time (Typ. Tr+Tf): 35 ms
Touch Screen: PCAP Touch (10 points)
Light Sensor: Supported
Optical Bonding: Supported
Signal Connector: VGA / DVI-D
Power: DC 12V
Touch Controller: USB
Dimensions (V x H x T) mm: 295 x 205 x 40
Operating Temperature: -20 to 70 °C
Storage Temperature: -20 to 70 °C
Relative Humidity: 5% to 90% RH

Features / Technical specifications

• Model: AMG-10IPHJ01T1
• 10.4" industrial waterproof LCD for outdoor and harsh environments
• PCAP 10-point touch support and USB touch controller
• Optical bonding and anti-glare glass for improved visibility
• High brightness 1000 nits with ambient light sensor for auto-dimming
• Inputs: VGA and DVI-D; Power: DC 12V
• Operating range: -20 to 70 °C; Relative humidity: 5%–90% RH
