Rotary position sensor AS5200Lcontactlesspotentiometermagnetic
Add to favorites
Compare this product
Characteristics
- Type
- rotary
- Contact / non-contact
- contactless
- Technology
- potentiometer, magnetic, PWM
- Output signal
- analog, digital output
- Applications
- industrial
- Supply voltage
5 V
- Ambient temperature
Max.: 125 °C
(257 °F)Min.: -40 °C
(-40 °F)
Description
12-bit programmable position sensor for contactless potentiometer applications
Features
Contactless angle measurement
Digital output over I2C or PWM-encoded output
Automatic magnet detection
MLF-16 (5mm x 5mm) package with wettable flanks
AEC-Q100 automotive qualified
Benefits
Highest reliability and durability
Accurate angle measurement
Simple programming
Low-power consumption
Suitable for safety critical automotive applications
Product parameters
Resolution [bit]: 12
Interfaces
Output: analog ratiometric, PWM or I2C
Max. Speed [rpm]
Overvoltage Protection
Redundant
Package: MLF-16
Automotive Qualified
