Embedded RFID reader board SMT-5

OEM

Product Introduction
We are a one-stop PCBA design and manufacturing partner for industrial electronics, bridging your concept to a market-ready embedded assembly. We offer custom PCB layout, component sourcing, SMT/DIP assembly, and full functional and electrical testing to deliver reliable embedded PCBA solutions for barcode and RFID reader OEMs.

Product Parameters
Key attributes: Base material: glass fibre (FR-4); Board thickness: 0.6–3.0 mm; Model: SMT-5; Brand: ASK; Copper thickness: 1–5 oz; Min. hole size: 0.2 mm; Min. line width/spacing: 0.1 mm; Board size: 5×5 mm to 500×600 mm; Surface finishing: lead-sprayed tin / lead-free tin / gold finger / immersion silver / immersion tin; Solder mask colors: green, yellow, blue, black, white; Standards: IPC-A-610 D / IPC-III; MOQ: 5 pieces; Testing: 100% electrical test; Certificates: ISO, RoHS, CE, CQC, IATF16949; Typical lead times: 1–1000 pcs: 3 days; 1001–10000 pcs: 7 days; >10000: to be negotiated.

Technical specifications

• Model: SMT-5
• Brand: ASK
• Base material: glass fibre (FR-4)
• Board thickness range: 0.6–3.0 mm
• Minimum hole size: 0.2 mm
• Minimum line width: 0.1 mm
• Minimum line spacing: 0.1 mm
• Copper thickness: 1–5 oz
• Board size range: 5×5 mm to 500×600 mm
• Surface finishing options: lead-sprayed tin, lead-free tin, gold finger, immersion silver, immersion tin
• Solder mask colors: green, yellow, blue, black, white
• Standards: IPC-A-610 D / IPC-III
• MOQ: 5 pieces
• Testing: 100% electrical test
• Certificates: ISO, RoHS, CE, CQC, IATF16949
• Typical lead times: 3–7 days depending on quantity
