Differential pressure transmitter PRE-50 G
4-20 mA0-10 V36VAC

Differential pressure transmitter - PRE-50 G - APLISENS S.A. - 4-20 mA / 0-10 V / 36VAC
Differential pressure transmitter - PRE-50 G - APLISENS S.A. - 4-20 mA / 0-10 V / 36VAC
Add to favorites
Compare this product
Go to the APLISENS S.A. website for more information

Characteristics

Pressure type
differential
Output
4-20 mA, 0-10 V
Supply voltage
36VAC
Process connection
M20 x 1,5
Material
brass
Other characteristics
smart, low pressure
Pressure range

Max.: 20,000 Pa
(2.9 psi)

Min.: 250 Pa
(0.04 psi)

Precision

0.3 %, 0.6 %, 1.6 %

Process temperature

Max.: 80 °C
(176 °F)

Min.: -25 °C
(-13 °F)

Description

The PRE-50G transmitter is applicable to gases, to the measurements of their pressure, underpressure and differential pressure. Typical applications include the measurement of blast pressure, chimney draughts or pressure / underpressure in furnace chambers. Installation The economical version can be mounted on any stable construction using the assembly fixture with Ć9 opening. The transmitter’s connection shanks have terminals to be connected to the elastic Ć6×1 impulse line. Where the pulse comes through a metal pipe, we suggest an M20×1.5 adapter for a Ć6×1 fitting using. The transmitter with a C type connector should be mounted on a 3- or 5-valve manifold. We recommend to use our preassembled transmitters with VM type valves (page IV/ 2).
