Wall-mount battery charger HERA

digitalmicroprocessor-controlled

Charger with seven LED board and an efficient charging system HERA LED offers a wide range of extremely robust and compact chargers, managed by a microprocessor control with 7 LED display suitable for every need. HERA LED is a reliable and compact charger with a Wa charging profile and a charging efficiency of more than 90%. Specifications - Display of charge status with 7 LEDs - Very high efficiency over 90% and Power factor of 0.80 allow low energy consumption - ON/OFF switch for enable or disable the charge - External push button for programmable equalizing and weekend charge - Quick test for charger functional verification - Maximum and minimum voltage control before charging starts - Maximum voltage control in charge - Final charging time that can be set to adapt the charge cycle to battery conditions - Serial interface for highly precise programming and calibration - Short circuit and reverse polarity protection - Design, testing and production of transformers carried out internally - Thermal protection on the power transformer to avoid over-temperature - Excellent ventilation system for better cooling of the transformer - Working temperature 0 – 50°C Technical characteristics / specifications - Charging system: Microprocessor controlled - Display: 7 LED indicators - Charging efficiency: >90% - Power factor: 0.80 - Protection: Short circuit, reverse polarity, thermal protection - Operating temperature: 0 – 50°C
