Wall-mount battery charger ZEUS

digital

Full range of chargers with LCD display for clear viewing of charge parameters ZEUS DIGITAL offers a wide range of chargers that contain the best digital and power technology. The DIGITAL card immediately displays the battery voltage, charging current, restored capacity, charging time. It also allows you to easily configure the functionality of the charger. The excellent charging efficiency is more than 90%. Specifications - Indication on LCD of charge parameters: Voltage, Current, reintegrated Capacity, charge Time - The simple keypad allows a safe configuration of the parameters: battery voltage, gas point voltage, final charging time, enabling equalization. - Charging Profile available: Wa, W0Wa, W0Wp, opportunity - Very high efficiency superior to 90% and Power factor of 0.80 allow low energy consumption and charging costs - Equalization Charge and Maintenance Charge with programmable parameters - Maximum and Minimum Voltage control before charging starts - Maximum voltage control during charge - Single board model from 12V to 96V - Serial interface for highly precise programming and calibration - Short circuit, overload and reverse polarity protection - IP20 intrusion protection - Thermal protection on the power transformer to avoid over-temperature - Conformal coating on the control card for moisture protection to grant high reliability - Excellent ventilation system for better cooling of the transformer - Working temperature 0 - 50°C Technical characteristics / specifications - LCD display for charge parameters - Configurable battery voltage, gas point voltage, final charging time, equalization - Charging profiles: Wa, W0Wa, W0Wp, opportunity - Efficiency: >90% - Power factor: 0.80 - Voltage range: 12V to 96V (single board model) - IP20 protection - Operating temperature: 0 - 50°C
