Platform loading ramp BIG FOOT - LLO 25 T

flexiblehandlingconstruction

Large Mobile dock ramp, uncouplable for many possibilities. Capacity: 25,000 Kg Overall length: 11.70 m Overall Width Exterior in mated version: 3.04 m / Width (Useful): 3.04 m Total width in uncoupled position: 1.524 m Penetrating lip: 30 cm Hydraulic crank leveling: Mini Height: 1.20 m - Max: 1.65 m 4 support crutches with adaptive heads, full hot-dip galvanized tray, anti-slip, 4 lashing chains. Ramp mounted on flexible solid tires, 2 adjustable support crutches per piece. Slopes: Min: 15.18 % - Max: 20.88 % Applications: Ideal for military applications, use in breakage, dump, sites requiring the loading / unloading of bulky machines, large machines. Disassembled in two identical mobile and independent parts, this one will allow you to unload all types of machines whatever its width. Its full access platform will allow you easy access to all types of material handling and construction. The two parts of this ramp are usable independently of one another, or together.
