Isolation transformer TTML series cast resinfor medical applicationslow-voltage
Add to favorites
Compare this product
Characteristics
- Type
- isolation
- Configuration
- cast resin
- Applications
- for medical applications
- Electrical characteristics
- low-voltage
- Mounting
- through-hole
- Other characteristics
- vacuum impregnation
- Electric power
Min.: 3.15 kVA
(4.2828 hp)Max.: 8 kVA
(10.877 hp)- Primary voltage
230 V
- Secondary voltage
Min.: 115 V
Max.: 230 V
Description
General Data
Rated input voltage 230 Vac
Rated output voltage 115 and 230 Vac
Rated power 3150 ‑ 8000 VA
Insulation class B
Maximum ambient temperature 40 °C
Efficiency up to 97 %
Degree of protection IP 00
Advantages
Safe galvanic isolation
PTC resistor built into every coil to set up an external monitoring unit for protection against overload
Very good switch‑on behaviour thanks to reduced starting currents
Very high efficiency
Very low short circuit voltage
Very low idle current
Very good corrosion protection and low noise thanks to BLOCKIMPEX vacuum impregnation
Contact protected screw connection terminals complying with UVV BGV A3
Low height
