Built-in electrical socket 6530x0001

Product description

• Connector type: USB Type-C
• Compatible devices: tablets, laptops, phones, smartwatches
• Compatible phone models: any device requiring USB-C charging
• Included components: flush-mounted USB-C charging unit, center plate and frame
• Special feature: fast charging (USB-C Power Delivery)
• Input voltage: 230 V AC
• Mounting type: flush-mounted
• RAL color: Anthracite (RAL 7016)
• Installation: for all standard flush-mounted boxes Ø 65 mm; installation according to DIN 49073
• Compatibility: compatible with 55 mm switch programs (frame inner size 55x55 mm), e.g., Busch Balance SI, GIRA Standard 55
• Power: 65 W USB-C Power Delivery fast charging; adjustable power up to 65 W
• Wiring: connection of wires up to max. 2x2.5 mm² for easy loop-through even in multiple frames
• Recommended locations: installation in kitchen, living room, bedroom, hallway and other indoor areas

Technical specifications (table)
Connection: screw terminal
Mounting types: flush-mounted
Color: Anthracite
Size: single unit
Frame: with frame

Characteristics / Specifications

• EAN: 4012096024774
• Product number / SKU: 6530x0001
• Input voltage: 230 V AC
• Maximum output power (USB-C PD): up to 65 W
• Connector type: USB Type-C (Power Delivery)
• Connection terminal: screw terminal
• Wire cross-section for connection: up to max. 2x2.5 mm²
• Installation: flush-mounted, Ø 65 mm, installation according to DIN 49073
• Frame/program compatibility: 55x55 mm (compatible with 55 mm switch programs)
• Color / finish: Anthracite (RAL 7016)
• Scope of delivery: flush-mounted charging unit, center plate, frame
