Belt conveyor BPB200

hydraulicinclinedtransport

Product Overview
The BPB200 track-mounted conveyor is a fully mobile, high-capacity tracked belt conveyor designed for efficient material handling on varied and demanding sites. Capable of handling up to 500 tons per hour, the BPB200 reduces the need for dedicated loaders in stockpile management and is suitable for crushed stone, sand, gravel, industrial waste, biomass and other construction materials.

Specifications

• Angle of conveyor: 12° - 22°
• Stockpile height: 6,740 - 9,820 mm
• Stockpile capacity: 565 - 1,746 m³

Key Benefits and Application
The BPB200 delivers high throughput and site mobility, reducing reliance on wheel loaders and minimizing equipment idle time. Its tracked configuration enables flexible positioning with secondary crushers, screens and mobile processing plants across changing site layouts.

Characteristics

• 1. High throughput capacity - Up to 500 t/h; track-mounted design enables efficient relocation around job sites while maintaining production rates.
• 2. Enhanced stockpiling capacity - Extended conveyor length and large distance between tracks and head drum maximise stockpile volume; adjustable front and rear telescopic sections allow customised discharge heights.
• 3. Cost-effective operation - Reduces the need for wheel loaders, lowering fuel consumption by up to 75% and operating costs by up to 70% compared with continuous loader operation.
• 4. User-friendly mobility and setup - Hydraulic folding mechanisms provide compact transport and rapid setup, typically in less than 20 minutes; hydraulic tail section height adjustment optimises stockpiling.
• 5. Throughput guidance - Throughput figures are based on a recommended running angle of 18°; to achieve quoted tonnage operate the conveyor at this angle.
• 6. Durable, serviceable design - Constructed from materials selected for extended service life in harsh environments; counter-weighted feed boot area enhances stability; folding head and tail sections simplify transport.

Optional Features

• Bolt-in feedboot liners: options include 6 mm steel wear liners, 6 mm hardened steel wear liners or bolt-in rubber liners.
• Adjustable feed gate: controls material flow; requires front plate removal to fold tail section.
• Fall break system: bolt-in fall break to protect the belt from large impact materials; requires front plate removal to fold tail section.
• Anti-roll back: up to four sets of anti-roll back fittings for incline operation to prevent material rollback.
• Conveyor side skirting: bolt-on rubber side skirting along conveyor length to reduce spillage.
• Belt weigher: integrated belt weighing system with control panel; optional USB data logger.
• Dust suppression system: dust covers along full conveyor length and head chute with rubber sock for dusty materials.

Technical specifications

• Model: BPB200
• Throughput: Up to 500 tons per hour
• Angle of conveyor: 12° - 22°
• Stockpile height: 6,740 - 9,820 mm
• Stockpile capacity: 565 - 1,746 m³
• Typical setup time: Less than 20 minutes
• Fuel consumption reduction: Up to 75% (vs. continuous loader operation)
• Operating cost reduction: Up to 70%
• Recommended running angle for quoted throughput: 18°
• Design features: track-mounted, hydraulic folding head and tail, counter-weighted feed boot, telescopic discharge sections, foldable components, wireless/PLC control options
