Motor-driven polisher FSA 571 KB

automaticfully-automaticstone

The FSA 571 KB is an edge and curve polisher designed for gravestone production. It performs automatic grinding and polishing of straight edges and small-radius curved edges via an integrated tool magazine with automatic tool change.

Key features

• Fully automatic grinding and polishing of gravestone edges (straight and curved)
• Integrated tool magazine with automatic tool change for sequential processing
• Grinding head automatically adapts to curved workpiece contours
• Multiple grinding programs available:
  • Rectangle
  • Zigzag
  • Offset
• Freely adjustable working length to process various workpiece sizes

Applications

• Designed for gravestone and memorial stone workshops
• Processing of straight edges, curved edges with small radii, chamfers and decorative contours
• Suitable for series production and sequential automated steps

Technical specifications

• Max. usable width: 3,500 mm
• Working length: any (freely adjustable)
• Max. workpiece thickness: 610 mm
• Main motor: 7 kW
• Feed: up to 20 m/min
• Tool slide rotation: 8×45° clamped
