Light optical sensor CX6-DP50for safety edgesstandard
Add to favorites
Compare this product
Characteristics
- Measured physical value
- light
- Applications
- for safety edges
- Mounting
- standard
Description
Product
Overview
Technical specifications
Mechanical / electrical parameters
Operating environment
Accessories & documentation
Notes
- Model: CX6-DP50
- Series: CX6 fiber sensor series
Overview
- Product type: Professional
- Output: PNP NO/NC
- Supply voltage: DC 12–24 V
- Wiring: 3-wire DC
- Protection rating: IP50
- Connection: Molded cable
Technical specifications
- Cable length: 2 m
- Response frequency: 2500 Hz / 500 Hz / 30 Hz
- Response time: 200 μs / 1 ms / 16 ms
- Light source: Red
- Key functions: one-touch setup, threshold adjustment, initialization, NO/NC switching, emission power setting, three detection speeds, three timer functions, digital display switch, power-saving mode
- Response modes: High-speed / Standard / High-precision
- Accessories: User manual, certificate
- Materials: Housing: PC; Cable: PVC
Mechanical / electrical parameters
- Output: PNP NO/NC
- Supply voltage: DC 12–24 V
- Wiring: 3-wire DC
- Protection rating: IP50
- Connection: Molded cable
- Signal type: Switching output
- Operating mode: Light ON / Dark ON
- Supply current: < 30 mA
- Protection circuits: Reverse polarity, output short-circuit protection, output reverse-connection protection, surge protection
- Power consumption: ≤ 720 mW (at 24 V: current < 30 mA; at 12 V: current ≈ 60 mA)
- Insulation resistance: > 20 MΩ
- Shock resistance: 150 m/s², 3 shocks each in X, Y, Z
- Dielectric strength: AC 1000 V 50/60 Hz 1 min (between charged parts and housing)
- Vibration resistance: 10–50 Hz, double amplitude 0.7 mm or 50 m/s², X/Y/Z 1.5 h each
- Weight: approx. 65 g
Operating environment
- Humidity: 25–85% RH (no icing, no condensation) for operation/storage
- Ambient illuminance: ≤ 10,000 lx
Accessories & documentation
- User manual and certificate included. Control output diagram and dimensional drawings available for download.
Notes
- For installation and detailed electrical diagrams consult the product documentation.
