Lubricated Venturi ejector CVPC series

single-stagefor machinescompact

The ultra-compact and light CVPC Series controlled vacuum cartridges are used to effortlessly install a vacuum generation system equipped with an electric control, as close to the corresponding application as possible. They perfectly meet the flexibility, customization and performance needs of machine manufacturers and integrators of robotic solutions, who want to easily design flexible, modular and efficient gripping tools. CVPC Series controlled vacuum cartridges are suitable for a broad variety of applications and are available in different sizes and suction capacities: . Size 1: nozzle dia. 1.2, 1.4 and 1.6 mm generating a suction flow rate ranging from 41 to 90 Nl/min. Max. vacuum 85%. . Size 2: nozzle dia. 2.2 and 2.7 mm generating a suction flow rate ranging from 160 to 215 Nl/min. Max. vacuum 85%. Advantages . Ultra-light and compact cartridge design allows for great flexibility and easy integration. . Integrated pilot control solenoid valve reduces response times. . Vacuum technology: powerful single-stage Venturi that is dust resistant and maintenance-free. Compact Integration The innovative and patented design of the CVPC Series controlled vacuum cartridges combines two integrated functions: . A single-stage Venturi that uses compressed air to generate a powerful vacuum, thus guaranteeing short evacuation times. The single-stage technology, consisting of a nozzle and a mixer, works without any moving parts, is dust resistant and maintenance-free. . An electro-pneumatic valve that controls compressed air in order to regulate vacuum, ensuring high reactivity and thus a quick response time, meeting the requirements of ultra-fast pick & place applications.
