Hydraulic bin lifter MOC 500

manual

The MOC 500 compact reliable binlift that can safely handle a 2 and 4 wheel containers containers with its robust rear mounted lift system. Note: This product is specifically engineered for use out of Europe. It encompasses many design elements suited to overseas operations, it is therfore not wholly complaint to EN1501 norm, which is required inside Europe. Compact design with minimum overhang to reduce risk of rear axle overloading Simple lever or push button operation Narrow and Wide versions to perfectly match all Olympus models Low weight design to to help optimise and achieve higher payloads Integrated mounting with Olympus Can be upgraded to handle skips with the addition of the industrial skip arm option SPECIFICATIONS Cycle Time: 2 and 4-wheel containers 13 sec. Skips 30 sec. Handling Capacity: 500kg Noise Level: < 65dB(A) Mounting Method: Integrated on Olympus tailgate Operation Mode: Manual Weight: 500kg Hydraulic Requirements: 20 l/min., 190 bar Auto-Gather: No Diagnostic Display: No
