Digital video microscope DermaScope® Wireless

for dermatologypolarizationhand-held

Product description
The Dino-Lite DermaScope® Wireless (MEDLW4DW) is a wireless digital dermatoscope featuring a 1.3 megapixel CMOS sensor and a built-in, fully adjustable linear polarizer to significantly reduce skin glare. It provides 10–50x magnification with a glass lens and anti-reflection coating and is intended for clinical use by physicians, dermatologists and skin specialists.

Key features

• 1.3 MP CMOS sensor (1280x1024)
• Built-in adjustable linear polarizer to reduce skin gloss
• 10–50x magnification with magnification lock (glass lens, AR coating)
• White LED illumination (8 LEDs), LED on/off switchable
• Wireless (WiFi) and USB 2.0 connectivity
• Compatible with Windows and macOS (DinoCapture / DinoXcope)

Lighting
Light / LED type: White
Number of LEDs: 8
LED on/off switchable: Yes
Infrared filter: IR cut-filter >650 nm
Diffuser available: No
Polarizer: Yes, linear (adjustable)

Optics
Magnification: 10–50x
Lens type: Glass lens with anti-reflection coating

Sensor
Sensor type: CMOS
Resolution: 1.3 Megapixel (1280x1024)
Maximum frame rate: 30 fps

Compatibility
Interface: USB 2.0; WiFi for wireless operation
Operating systems: Windows 7/8/10/11, macOS 10.9 and later
Software: DinoCapture 2.0 (Windows), DinoXcope (macOS)
Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows): WMV, FLV, SWF
Supported image formats (macOS): JPEG, PNG
Supported video formats (macOS): MOV
Imaging standards: DirectShow, UVC

Housing
Housing material: Composite / plastic
Magnification lock: Yes
Dimensions: 10.5 cm (L) x 3.2 cm (D)
Weight: 105 g
Cable length (when used wired): 1.8 m

Features
Special feature: Built-in adjustable polarizer
Measurement: No integrated measurement function
Calibration: No
Microtouch sensor: Yes

Information
Package contents: Microscope, carry pouch, software CD, user manual, N3C-C, N3C-L
Warranty information: 2 years European warranty
Regulatory approval: Medical Device Class 1 – Medical Devices Regulation (EU) 2017/745
Price range (indicative): €900.00 - €1,100.00

Technical specifications

• Product Code: MEDLW4DW
• Brand: Dino-Lite
• Model: DermaScope® Wireless
• Sensor: 1.3 MP CMOS (1280x1024)
• Frame rate: up to 30 fps
• Magnification: 10–50x
• Lens: Glass with anti-reflection coating
• Illumination: 8 white LEDs, switchable
• Polarizer: Adjustable linear polarizer
• Interfaces: USB 2.0 and WiFi
• OS compatibility: Windows 7/8/10/11, macOS 10.9+
• Housing: Composite / plastic
• Dimensions: 10.5 cm L x 3.2 cm D
• Weight: 105 g
• Warranty: 2 years (Europe)
