Aluminium crate Mehrweggebinde

transportstoragehandling

Overview
Multi‑trip packaging solutions include reusable transport containers, stacking pallets and skeleton transport boxes designed to organise the site, reduce search time and streamline storage and handling of system components, small parts and accessories. Stacking pallets simplify storage and handling of floor props, folding tripods, formwork beams and panels. Skeleton transport boxes are suitable for lighter accessories (max. load 700 kg); multi‑trip transport boxes accommodate heavier accessories (max. load 1,500 kg).

Benefits

• Faster loading and unloading of system components, small parts and accessories
• Quick relocation between work areas by crane or with bolt‑on castors
• Safe stacked storage even in confined spaces, reducing handling time and equipment/labour cost

Mobility & handling
Stacking pallets and containers can be fitted with bolt‑on castor sets or handled by crane for flexible on‑site relocation. When equipped with castors, pallets enable ergonomic, quick movement including passing through door openings on building sites.

Components and capacities

• Stacking strap 50 Alu — for secure transport of formwork sheets and panels; max. tensile force: 40 kN
• Doka multi‑trip transport box — max. load capacity: 1,500 kg
• Doka stacking pallet — max. load capacity: 1,100 kg
• Doka accessory box — max. load capacity: 1,000 kg
• Alu‑Framax pallet — max. load capacity: 1,200 kg; delivered folded (e.g. capacity for 8 panels 0.75 m x 2.70 m)
• Doka skeleton transport box — max. load capacity: 700 kg
• Frami pallet — max. load capacity: 800 kg

Technical specifications

• Stacking strap 50 Alu — max. tensile force: 40 kN
• Multi‑trip transport box — max. load capacity: 1,500 kg
• Stacking pallet — max. load capacity: 1,100 kg
• Accessory box — max. load capacity: 1,000 kg
• Alu‑Framax pallet — max. load capacity: 1,200 kg; folded delivery for compact storage (example: 8 panels 0.75 m x 2.70 m)
• Skeleton transport box — max. load capacity: 700 kg
• Frami pallet — max. load capacity: 800 kg
