Wooden formwork girder Top 100 tec

Product overview
Based on the heavy-duty Beam I tec 20, the Large-area formwork Top 100 tec provides precise dimensional control under high fresh-concrete pressures and widely spaced form-ties. Element shape, dimensions, tie-hole grid and form-facing can be adapted to project requirements.

Lower labour costs
due to optimised waling planes

• Large tie-hole pattern while maintaining the same permissible fresh-concrete pressure
• Up to 30% fewer form-tie points reduces installation costs
• Up to 30% fewer connectors reduces manhours

Fast pouring
enabled by the high permitted fresh-concrete pressure

• Can be dimensioned for easy-workability and self-compacting concretes
• Key component: heavy-duty I tec 20 beam
• Top100 tec waling WU14 and Tie-rod system 20.0

Cuts costs in the civil engineering field
through efficient equipment utilisation

• Reduced material usage and simpler site erection; parallel girder-frame units can be spaced wider on bridges
• Optimised hole-grid allows flexible installation of form-ties and accessories such as spindle struts
• Continuous adaptability to the desired tie-hole pattern

Architectural stipulations can be realised economically
large tie-hole patterns and rear-fixed form-facing permit high-quality concrete finishes

• Stiffer elements improve surface planeness
• Form-facing screwed from the rear avoids screw-head imprints
• Optimised element connector reduces bleeding

Comprehensive workplace safety
compatible ladderways and working platforms ensure safe access and handling

• Safe vertical access with the Ladder system XS
• All-round workplace safety with the Platform system Xsafe plus
• Accessories such as panel struts and lifting/repositioning devices facilitate safe handling

References / suitable applications
Used on bridge and tunnel projects and high-rise/commercial construction; compatible components are available to match the system.

Technical specifications

• System/series: Top 100 tec
• Based on: Beam I tec 20 (heavy-duty timber beam)
• Waling: Top100 tec waling WU14
• Tie system: Tie-rod system 20.0
• Designed for high permissible fresh-concrete pressures and widely spaced form-ties
• Large, optimised tie-hole grid for flexible form-tie patterns and accessory installation
• Form-facing fixed from the rear to avoid screw-head imprints
• Compatible safety/accessory systems: Ladder system XS, Platform system Xsafe plus, panel struts, lifting/repositioning devices
• Intended benefits: reduced installation time, fewer connectors, reduced material usage, improved concrete surface finish and dimensional accuracy
