Slab prop Eurex series

galvanised steellight-dutytelescopic

Product overview
Doka floor props are adjustable vertical supports for temporary shoring of slabs and formwork on construction sites. Available in galvanised steel and aluminium versions, the Eurex family covers a wide range of extension lengths and load classes in accordance with EN 1065, with certified minimum capacities from approximately 20 kN up to 128 kN depending on model.

Choose your Doka floor prop

• Eurex top
• Eurex eco
• Floor prop XN
• Eurex 20 basic
• Eurex 60
• Eurex 100 Plus

Eurex top

• Load classes: EN 1065 — Class C/D (min. 20 kN) and C/E (min. 30 kN)
• Durability: impact protector and high‑quality galvanised finish
• Easy adjustment: special thread geometry for effortless nut rotation
• Low weight: reduces handling effort on site
• Height setting: permanently numbered pegging holes

Eurex eco

• Load classes: EN 1065 — Class B/D (min. 20 kN) and C/E (min. 30 kN)
• Fast height adjustment: numbered and engraved pegging holes
• Safe release under load: optimised thread pitch
• Low dead weight: speeds up handling and conserves operator energy
• Safety: handtrap prevention and anti‑dropout latch
• Long service life: forged adjusting nut and high‑quality galvanisation

Floor prop XN

• Cost‑effective solution: designed for economical slab propping
• Durable finish: galvanised steel construction
• Easy handling: low weight and simple assembly
• Release under load: optimised thread angle for safe loosening

Eurex 20 basic

• Certified capacity: min. 20 kN for typical extension lengths (model‑specific limits apply)
• Ergonomic design: weight reduction vs conventional B/D class props
• Cost efficient: optimised materials and manufacturing for long durability
• Simple maintenance: special thread geometry for easier nut loosening under load

Eurex 60

• Aluminium prop: standard extension range 3.50–5.50 m
• Maximum capacity: up to ~88.9 kN depending on extension
• Extendable: can be extended with reduced capacity (extensions and adapters available)
• Applications: also usable as adjustment prop for high wall formwork and precast elements

Eurex 100 Plus

• High capacity aluminium prop: extension range typically 1.70–5.50 m
• Top load classes: certified capacities up to ~128 kN depending on model
• Fast stripping: jack nut with large thread pitch
• Release under load: double thread for safe detachment
• Reduced cleaning: self‑cleaning thread
• Extended functions: compatible with extra screwjack mechanisms

Common safety & durability features

• Handtrap‑prevention design
• Anti‑dropout safeguard / locking latch
• Forged adjusting nut on relevant models
• Galvanised finish for corrosion protection (steel versions)
• Ergonomic fastening clamp to reduce handling effort

Technical specifications

• Standards & classes: EN 1065 load classes (examples: B/D, C/D, C/E) with certified minimum capacities from ~20 kN and model‑dependent maxima up to ~128 kN
• Materials: galvanised steel for many models; aluminium construction on selected high‑range models
• Extension ranges: model dependent (examples: Eurex 20 series ~up to 3.16–7.00 m depending on variant; Eurex 60 nominal 3.50–5.50 m, extendable; Eurex 100 Plus 1.70–5.50 m)
• Handling: reduced dead weight variants for faster and less strenuous handling
• Accessories: extensions, couplers and extra screwjack mechanisms available depending on model
