Plano-convex lens element #38-707

cylindricalfused silicalaser

Overview
TECHSPEC® Laser Grade Plano‑Convex (PCX) lenses are engineered for high‑energy Nd:YAG laser systems used in cutting, machining and welding. The precision fused silica substrate (Corning 7980), with λ/10 transmitted wavefront accuracy and 10‑5 surface quality, minimizes scatter and preserves beam quality. Lenses are available uncoated or with high laser‑damage‑threshold (LDT) anti‑reflection (AR) coatings optimized for common Nd:YAG wavelengths to maximize transmission.

Key features

• Designed for high‑energy Nd:YAG laser applications (cutting, machining, welding)
• Precision fused silica substrate for low scatter and excellent transmitted wavefront
• Surface accuracy: λ/10 (transmitted wavefront)
• Surface quality: 10‑5
• Offered uncoated or with high‑LDT AR coatings at common Nd:YAG wavelengths

Product family highlights

• Guaranteed laser damage threshold for specified coatings
• Multiple diameters and effective focal lengths available
• Manufactured to tight tolerances for repeatable beam delivery

Applications

• Nd:YAG laser systems and modules
• Laser cutting and material processing
• High‑energy laser machining and welding
• Beam delivery and focusing optics in industrial laser setups

Coating options

• Uncoated for broadband use or high‑LDT AR coatings for specific wavelengths
• Common LDT AR wavelengths: examples include 266 nm, 355 nm, 532 nm, 1064 nm

Technical specifications

• Family: Laser Grade Plano‑Convex (PCX) lenses
• Substrate material: Precision fused silica (Corning 7980)
• Surface quality: 10‑5
• Surface accuracy: λ/10 (transmitted wavefront)
• Bevel: Protective as needed
• Coating options: Uncoated or multiple high‑LDT AR coatings optimized for Nd:YAG wavelengths
• Typical uses: high‑energy laser optics for Nd:YAG cutting, machining and welding
