Ball valve INCAS V series

manualfor waterthreaded

TECHNICAL FEATURES: Temperature limits: for fluids from –10°C to +90°C Pressure limits: for fluids PN 10 (20°C) SPECIFIC FEATURES: • The INCAS V valve has been designed to offer the possibility to replace the sealing if necessary, without replacing the complete ball valve. incas-extra-K2501• The new patented conical sealing system, allows long life performances and higher flow rate. • Extension sets (K250) to lengthen the distance between valve and accessories (15 mm and multiple) are available. Application fields: The INCAS VITON valve is suitable for heating and sanitary installations. Threaded end connections: • Standard female according to a special UNI ISO 228/1. Operation devices: Knob with rosette (K210) and extension, lever with rosette (K200) and extension, cap with operation key (K204), 15mm extension (K250). All the valves comply with the regulation 97/23/CE and are tested 100% on pneumatic seal with electronic control.
